System And Components
250-1887 DRIVE GP-FAN
Group No: 250-1887 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1117238 | 1 PLATE (THRUST) | 1 | |
| 1230856 | 2 SHAFT-FAN | 1 | |
| 1900634 | 3 BELT TENSIONER | 1 | |
| 3079798 | 4 BEARING AS | 1 | |
| 2014118 | 5 PULLEY-FAN (8-GROOVE) | 1 | |
| 2015149 | 6 SUPPORT AS-FAN | 1 | |
| 5B5821 | 6A DOWEL | 1 | |
| 2015151 | 7 BRACKET | 1 | |
| 2015152 | 8 SPACER | 1 | |
| 2075992 | 9 BRACKET | 1 | |
| 2112101 | 10 SLEEVE | 2 | |
| 2267914 | 11 BRACKET (FAN BEARING) | 1 | |
| 2285827 | 12 RETAINER-BEARING | 1 | |
| 2792589 | 13 PULLEY AS-IDLER (8-GROOVE) | 1 | |
| 2892033 | 14 BELT TENSIONER | 1 | |
| 2893033 | 15 PULLEY AS-IDLER | 1 | |
| 6V9027 | 15A SEAL-O-RING | 1 | |
| 2089298 | 15B BOLT-FLANGE HEAD (M10X1.5X60-MM) | 1 | |
| 2899340 | 16 BRACKET-MOUNTING (BELT TENSIONER) | 1 | |
| 1327551 | 17 SPACER (11X19X6-MM THK) | 1 | |
| 6V1820 | 18 BOLT (M10X1.5X30-MM) | 4 | |
| 6V3822 | 19 BOLT (M10X1.5X35-MM) | 3 | |
| 6V3940 | 20 BOLT (M8X1.25X25-MM) | 5 | |
| 6V4248 | 21 BOLT (M10X1.5X25-MM) | 1 | |
| 6V5215 | 22 BOLT (M8X1.25X16-MM) | 1 | |
| 6V5217 | 23 BOLT (M8X1.25X20-MM) | 9 | |
| 6V5219 | 24 BOLT (M8X1.25X40-MM) | 2 | |
| 6V5839 | 25 WASHER (11X21X2.5-MM THK) | 13 | |
| 6V5842 | 26 BOLT (M10X1.5X40-MM) | 4 | |
| 8T4172 | 27 BOLT (M10X1.5X80-MM) | 1 | |
| 7X2545 | 28 BOLT (M10X1.5X150-MM) | 1 | |
| 9M1974 | 29 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 8T4121 | 30 WASHER-HARD (11X21X2.5-MM THK) | 1 |
