System And Components
Assembly
100%

215-1818 GEAR GP-REARFOR USE WITH 215-1819, 215-1820, 215-1821, 215-1822, SAE NO. 1 FLYWHEEL HOUSING FOR REAR POWER TAKE-OFF

Group No: 215-1818 · Commonality
Part NumberPart NameQty
5F03041 PLUG-DRAIN (5/8-18-THD)1
5P41412 BOLT-SELF-LOCKING (1/2-13X1.75-IN)6
22647573 SEAL GP-CRANKSHAFT1
7C1728SEAL-CRANKSHAFT (REAR)1
1076280SEAL-O-RING1
29460074 BOLT-HEAD LOCKING (M6X1X18-MM)9
09592325 BOLT-SOCKET HEAD (M12X1.75X95-MM)4
15313257 SHAFT-IDLER GEAR3
17774638 HOUSING-FLYWHEEL1
21380959 PLATE AS1
7N5683DOWEL2
8M9315BUSHING2
061945510 SEAL-O-RING1
108178211 BOLT-SOCKET HEAD (M12X1.75X90-MM)1
147372312 GEAR AS-IDLER (49-TEETH)2
1527254BUSHING1
151133913 GEAR AS-IDLER (70-TEETH)1
1527254BUSHING1
178627914 GEAR (63-TEETH)1
2A116215 GASKET1
3E691016 BOLT-SOCKET HEAD (M12X1.75X70-MM)1
5P781417 SEAL-O-RING6
5P824518 WASHER-HARD (13.5X25.5X3-MM THK)16
6V424819 BOLT (M10X1.5X25-MM)2
309513020 PLUG AS1
2147566SEAL-O-RING1
9S4182PLUG (7/16-20-THD)1
6V513421 SEAL-O-RING1
6V568422 BOLT (M12X1.75X45-MM)9
6V569623 BOLT (M12X1.75X80-MM)3
6V583924 WASHER (11X21X2.5-MM THK)2
6V767325 BOLT (M12X1.75X50-MM)2
6V798126 BOLT (M10X1.5X70-MM)5
6V800427 BOLT (M12X1.75X120-MM)5
6V833628 BOLT (M12X1.75X70-MM)2
7X773029 PLUG-PIPE1
8T010630 BOLT (M12X1.75X100-MM)3
8T699131 BOLT (M12X1.75X180-MM)1
9M116432 COVER1
9S800334 PLUG (1/2-20-THD)6
9X457635 SEAL-O-RING1
9X826736 WASHER (6.6X12X2-MM THK)9
1U884637 SEALANT-GASKET
