Assembly
100%

215-7745 GEAR GP-REARType 2

Group No: 215-7745 · Commonality
Part NumberPart NameQty
1T08081 WASHER (0.516X0.812X0.09-IN THK)3
4P36472 GEAR AS (43-TEETH)1
9M24182A BUSHING1
4P41783 WASHER-THRUST1
4P41814 WASHER-THRUST1
7C14455 COVER1
29460076 BOLT-HEAD LOCKING (M6X1X18-MM)23
48583237 GEAR-CRANKSHAFT (46-TEETH)1
10952928 SHAFT-IDLER GEAR1
14242059 GEAR (40-TEETH)1
145661710 ADAPTER AS1
3F6795DOWEL2
163935811 GASKET1
213808712 HOUSING AS1
3F6795DOWEL6
5S854312A BUSHING1
213809013 PLATE1
215774214 SHAFT AS1
4B9880BALL1
215774415 CARRIER AS1
5S854315A BUSHING1
226475716 SEAL GP-CRANKSHAFT1
7C1728SEAL-CRANKSHAFT (REAR)1
1076280SEAL-O-RING1
061945517 SEAL-O-RING1
228172621 COVER1
389372822 PLUG AS1
2385084SEAL-O-RING1
3603684PLUG1
5P824523 WASHER-HARD (13.5X25.5X3-MM THK)11
6V119725 SEAL-O-RING1
6V394026 BOLT (M8X1.25X25-MM)4
6V513429 SEAL-O-RING1
6V519230 BOLT-SOCKET HEAD (M8X1.25X30-MM)6
6V523031 BOLT (M10X1.5X60-MM)2
6V583932 WASHER (11X21X2.5-MM THK)2
6V767333 BOLT (M12X1.75X50-MM)2
6V819734 BOLT (M12X1.75X40-MM)9
6V821435 BOLT (M6X1X20-MM)2
7X087036 BOLT (M8X1.25X140-MM)2
307267337 PLUG AS3
9S8005PLUG (3/4-16-THD)1
2385080SEAL-O-RING1
8T026938 BOLT-SOCKET HEAD (M6X1X20-MM)1
8T027339 BOLT-SOCKET HEAD (M12X1.75X40-MM)3
8T395740 BOLT-SOCKET HEAD (M12X1.75X30-MM)8
9M197441 WASHER-HARD (8.8X16X2-MM THK)6
485378846 SEAL-FACE1
9X728747 SEAL-O-RING1
9X826748 WASHER (6.6X12X2-MM THK)26
1U884652 SEALANT-GASKET
389370853 PLUG AS2
2147568SEAL-O-RING1
3603679PLUG-CONNECTOR (9/16-18-THD)1
309513054 PLUG AS1
2147566SEAL-O-RING1
9S4182PLUG (7/16-20-THD)1
