System And Components
271-7416 GEAR GP-REARS/N JSC1-UP; REH1-7475
Group No: 271-7416 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5F0304 | 1 PLUG-DRAIN (5/8-18-THD)(REAR GEAR HOUSING) | 1 | |
| 9X2022 | 2 BOLT-SELF-LOCKING (M6X1X20-MM) | 9 | |
| 2264757 | 3 SEAL GP-CRANKSHAFT | 1 | |
| 2717419 | 4 HOUSING AS-FLYWHEEL | 1 | |
| 4N0684 | DOWEL | 2 | |
| 8M9315 | BUSHING | 2 | |
| 2717422 | 5 RETAINER-GEAR | 3 | |
| 2717423 | 6 COVER-GEAR | 1 | |
| 2717426 | 7 COVER-ACCESS | 2 | |
| 2733712 | 8 SEAL | 1 | |
| 0619455 | 9 SEAL-O-RING | 1 | |
| 1473723 | 10 GEAR AS-IDLER (49-TEETH) | 2 | |
| 1527254 | BUSHING | 1 | |
| 1511339 | 11 GEAR AS-IDLER (70-TEETH) | 1 | |
| 1527254 | BUSHING | 1 | |
| 1786279 | 12 GEAR (63-TEETH) | 1 | |
| 1896123 | 13 BOLT-12 POINT HEAD (M12X1.75X60-MM) | 9 | |
| 2A1162 | 14 GASKET | 1 | |
| 3E8016 | 15 BOLT-SELF-LOCKING (M8X1.25X25-MM) | 8 | |
| 5P8245 | 16 WASHER-HARD (13.5X25.5X3-MM THK) | 25 | |
| 1U8846 | 17 SEALANT-GASKET | ||
| 2735039 | 18 SEAL-O-RING | 2 | |
| 6V3940 | 19 BOLT (M8X1.25X25-MM) | 4 | |
| 6V4248 | 20 BOLT (M10X1.5X25-MM) | 2 | |
| 3893707 | 23 PLUG AS | 1 | |
| 5P9436 | PLUG | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 6V5134 | 24 SEAL-O-RING | 1 | |
| 6V5684 | 25 BOLT (M12X1.75X45-MM) | 10 | |
| 6V5839 | 26 WASHER (11X21X2.5-MM THK) | 2 | |
| 6V8004 | 27 BOLT (M12X1.75X120-MM) | 6 | |
| 7X7730 | 28 PLUG-PIPE | 1 | |
| 9M1164 | 29 COVER | 1 | |
| 9M1974 | 30 WASHER-HARD (8.8X16X2-MM THK) | 12 | |
| 3960423 | 31 PLUG AS | 1 | |
| 3603690 | PLUG (7/16-20-THD) | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 3893708 | 32 PLUG AS | 7 | |
| 3603679 | PLUG-CONNECTOR (9/16-18-THD) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 9X4576 | 33 SEAL-O-RING | 1 | |
| 9X8267 | 34 WASHER (6.6X12X2-MM THK) | 9 |
