System And Components
233-2744 PUMP GP-ENGINE OILS/N CPT1-99999
Group No: 233-2744
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5C1796 | 1 GASKET | 1 | |
| 6I0260 | 2 BOLT (M8X1.25X25-MM) | 6 | |
| 6I0291 | 3 NUT (M8X1.25-THD) | 1 | |
| 6I4374 | 4 BOLT (M8X1.25X60-MM) | 2 | |
| 0676933 | 5 GASKET | 1 | |
| 1068916 | 6 BOLT (M6X1X16-MM) | 2 | |
| 1127702 | 7 HOUSING AS | 1 | |
| 6I0787 | 7A RING-RETAINING | 1 | |
| 7W4648 | 7B SEAT-SPRING | 1 | |
| 7W4650 | 7C SPRING | 1 | |
| 7W4782 | 7D PLUNGER | 1 | |
| 1243815 | 8 BOLT (M8X1.25X16-MM) | 1 | |
| 1336105 | 9 TUBE AS | 1 | |
| 1336106 | 10 BOLT | 2 | |
| 1344139 | 11 STUD | 1 | |
| 1836318 | 12 TUBE AS | 1 | |
| 1895601 | 12A SEAL-O-RING | 1 | |
| 2168625 | 13 PUMP AS-ENGINE OIL | 1 |
