System And Components
202-4098 LINES GP-BOOM CYLINDERS/N BDK2001-99999
Group No: 202-4098
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1017398 | 1 BOLT-SOCKET HEAD (M10X1.5X40-MM) | 8 | |
| 1053477 | 2 BOLT-SOCKET HEAD (M10X1.5X45-MM) | 8 | |
| 1132004 | 3 BOLT-SOCKET HEAD (M12X1.75X45-MM) | 4 | |
| 1374199 | 4 TUBE AS | 1 | |
| 1394016 | 5 INSERT-RUBBER | 2 | |
| 1457166 | 6 VALVE GP-MANUAL (BOOM LOWERING CONTROL) | 1 | |
| 1457713 | 7 BLOCK | 2 | |
| 1488440 | 8 TEE AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 8C0569 | TEE-O-RING | 1 | |
| 1514737 | 9 TUBE AS | 1 | |
| 1521267 | 10 ELBOW | 1 | |
| 1911381 | 11 ADAPTER | 4 | |
| 1916237 | 12 FITTING | 1 | |
| 1905287 | 13 ORIFICE | 1 | |
| 2090592 | 14 CLAMP AS | 1 | |
| 2090593 | 15 CLAMP AS | 1 | |
| 2126763 | 16 HOSE AS | 1 | |
| 2126764 | 17 HOSE AS | 1 | |
| 2126765 | 18 HOSE AS | 1 | |
| 2126766 | 19 HOSE AS | 1 | |
| 2180567 | 20 HOSE AS | 1 | |
| 2244793 | 21 HOSE AS | 1 | |
| 2253394 | 22 ACCUMULATOR GP-HYDRAULIC (CHARGED) | 4 | |
| 2268353 | 23 HOSE AS | 1 | |
| 2276003 | 24 CLAMP | 4 | |
| 2299686 | 25 HOSE AS | 1 | |
| 2310448 | 26 ORIFICE | 1 | |
| 1017404 | 27 BOLT-SOCKET HEAD (M10X1.5X30-MM) | 4 | |
| 1171823 | 28 CLAMP-SINGLE | 1 | |
| 1374279 | 29 CLAMP-SINGLE | 1 | |
| 1395751 | 30 CLAMP-SINGLE | 2 | |
| 1407599 | 31 CLAMP | 1 | |
| 1488367 | 32 ELBOW AS | 2 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9850 | ELBOW | 1 | |
| 1488371 | 33 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8C8988 | ELBOW | 1 | |
| 1488395 | 34 PLUG AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 9S8005 | PLUG (3/4-16-THD) | 1 | |
| 1488417 | 35 REDUCER AS | 2 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8941 | REDUCER | 1 | |
| 1488433 | 36 TEE AS | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V9836 | TEE-SWIVEL | 1 | |
| 1488434 | 37 TEE AS | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V9843 | TEE | 1 | |
| 1488451 | 38 TEE AS | 2 | |
| 6V8791 | TEE-FACE SEAL | 1 | |
| 6V9746 | SEAL-O-RING | 3 | |
| 1536237 | 39 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9004 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1P3702 | 40 SEAL-RECTANGULAR | 4 | |
| 1P3703 | 41 SEAL-RECTANGULAR | 2 | |
| 3J1907 | 42 SEAL-O-RING | 1 | |
| 3K0360 | 43 SEAL-O-RING | 1 | |
| 4J5267 | 44 SEAL-O-RING | 3 | |
| 5K9090 | 45 SEAL-O-RING | 2 | |
| 5P7468 | 46 CLIP (SLOT) | 2 | |
| 5P7469 | 47 CLIP (TAB) | 2 | |
| 5P8444 | 48 GROMMET (37-MM ID) | 2 | |
| 6V0400 | 49 FLANGE-HALF | 4 | |
| 6V8397 | 50 SEAL-O-RING | 3 | |
| 8T4121 | 51 WASHER-HARD (11X21X2.5-MM THK) | 16 | |
| 8T4182 | 52 BOLT (M10X1.5X45-MM) | 8 | |
| 8T4185 | 53 BOLT (M10X1.5X50-MM) | 2 | |
| 8T4223 | 54 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 8T4956 | 55 BOLT (M12X1.75X35-MM) | 2 | |
| 8T5005 | 56 BOLT (M10X1.5X70-MM) | 4 | |
| 8T9403 | 57 FLANGE-HALF | 8 | |
| 9X6580 | 58 NUT (1-3/16-12-THD) | 2 | |
| 9X6772 | 59 STRAP-CABLE | 6 |
