System And Components
185-3443 LINES GP-DIVERTER VALVES/N H2D576-UP
Group No: 185-3443
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3477715 | 1 FITTING GP-HYDRAULIC | 2 | |
| 8T9403 | 2 FLANGE-HALF | 8 | |
| 1017398 | 3 BOLT-SOCKET HEAD (M10X1.5X40-MM) | 8 | |
| 1348221 | 4 BOLT (M10X1.5X120-MM) | 4 | |
| 2909591 | 5 VALVE GP-DIVERTER (BOOM CYL, HEAD END) | 1 | |
| 3304657 | 6 TUBE AS | 1 | |
| 1518866 | 7 ELBOW | 2 | |
| 2909589 | 8 VALVE GP-DIVERTER (BOOM CYL, ROD END) | 1 | |
| 8T4198 | 9 BOLT (M10X1.5X100-MM) | 4 | |
| 1965382 | 10 HOSE AS | 1 | |
| 1965383 | 11 HOSE AS | 1 | |
| 1965384 | 12 HOSE AS | 1 | |
| 1P3702 | 13 SEAL-RECTANGULAR | 4 | |
| 4J5267 | 14 SEAL-O-RING | 2 | |
| 6V9746 | 15 SEAL-O-RING | 2 | |
| 2802747 | 16 BOLT-SOCKET HEAD (M10X1.5X60-MM) | 4 | |
| 8T4121 | 17 WASHER-HARD (11X21X2.5-MM THK) | 16 | |
| 8T4182 | 18 BOLT (M10X1.5X45-MM) | 16 |
