System And Components
265-5081 HOUSING GP-FRONT
Group No: 265-5081
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3560955 | 1 GEAR AS-DRIVE | 1 | |
| 5P6727 | 1A BALL BEARING | 1 | |
| 8H9789 | 1B BALL BEARING | 1 | |
| 2219357 | 1C GEAR-AUXILIARY DRIVE (40-TEETH) | 1 | |
| 2514314 | 3 ADAPTER | 1 | |
| 4394636 | 4 COVER AS | 1 | |
| 2572015 | 6 GASKET | 1 | |
| 2237852 | 7 SEAL-INTEGRAL | 1 | |
| 2264755 | 8 SEAL GP-CRANKSHAFT (FRONT) | 1 | |
| 2203373 | SEAL-RING | 1 | |
| 3293062 | 9 HOUSING AS-FRONT | 1 | |
| 6V3535 | 9A DOWEL | 2 | |
| 1178801 | 10 SEAL-O-RING | 1 | |
| 6V2317 | 11 BOLT (M8X1.25X30-MM) | 17 | |
| 6V5192 | 12 BOLT-SOCKET HEAD (M8X1.25X30-MM) | 3 | |
| 6V5219 | 13 BOLT (M8X1.25X40-MM) | 9 | |
| 6V8225 | 14 NUT (M6X1-THD) | 5 | |
| 3E8016 | 15 BOLT-SELF-LOCKING (M8X1.25X25-MM) | 1 | |
| 9M1974 | 16 WASHER-HARD (8.8X16X2-MM THK) | 30 | |
| 9X8256 | 17 WASHER (6.6X12X2-MM THK) | 5 | |
| 1833408 | 18 PLUG AS | 1 | |
| 2147568 | 18A SEAL-O-RING | 1 | |
| 9S8004 | PLUG (9/16-18-THD) | 1 |
