System And Components
287-3209 PAN GP-OIL -ENGINEPROVIDES A FRONT SUMP ENGINE OIL PAN
Group No: 287-3209
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9X6451 | 1 PLUG-DRAIN (MAGNETIC)(ENGINE OIL PAN) | 2 | |
| 2101744 | 2 BELL AS-SUCTION | 1 | |
| 2101743 | ELBOW | 1 | |
| 2173673 | 3 SEAL-ISOLATION | 1 | |
| 3010113 | 4 PAN-OIL | 1 | |
| 0619458 | 5 SEAL-O-RING | 2 | |
| 3E8016 | 6 BOLT-SELF-LOCKING (M8X1.25X25-MM) | 2 | |
| 5P7701 | 7 SEAL-O-RING | 2 | |
| 5P8211 | 8 SEAL-O-RING | 1 | |
| 5P8245 | 9 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 6A5591 | 10 BOLT (M12X1.75X25-MM) | 2 | |
| 3095130 | 11 PLUG AS | 1 | |
| 2147566 | 11A SEAL-O-RING | 1 | |
| 9S4182 | 11B PLUG (7/16-20-THD) | 1 | |
| 9M1974 | 12 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 9S9334 | 14 PLUG (1-5/16-12-THD) | 2 |
