System And Components
295-4608 COMBUSTION GP-EXHAUSTS/N LEE1279-4816
Group No: 295-4608
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 6 | |
| 2041611 | 2 STRAP-CABLE (DUAL) | 2 | |
| 2771873 | 3 CLIP (LADDER) | 1 | |
| 2890728 | 4 NUT (M8X1.25-THD) | 2 | |
| 2893107 | 5 GASKET | 1 | |
| 2900113 | 6 CLIP | 1 | |
| 2903930 | 7 BOLT (M8X1.25X55-MM) | 2 | |
| 2916641 | 8 CLIP | 1 | |
| 2952713 | 9 TUBE AS | 1 | |
| 2953099 | 10 SPARK PLUG (AFTERTREATMENT REGEN DEVICE) | 1 | |
| 3003950 | 11 COMBUSTION GP-EXHAUST | 1 | |
| 3008688 | 12 CLAMP-BAND | 1 | |
| 3053020 | 13 BRACKET AS | 1 | |
| 8T2321 | NUT-WELD (M8X1.25-THD) | 1 | |
| 3067473 | 14 SUPPORT AS | 1 | |
| 1325789 | 15 CLIP (LADDER) | 1 | |
| 2901993 | 16 STRAP-CABLE | 3 | |
| 2956240 | 17 WIRE AS | 1 | |
| 3E4352 | 18 WASHER-HARD (8.8X20.5X2.5-MM THK) | 4 | |
| 3T0849 | 19 BOLT-SOCKET HEAD (M6X1X25-MM) | 1 | |
| 4P7581 | 20 CLIP (LADDER) | 1 | |
| 5P7970 | 21 NUT (M8X1.25-THD) | 2 | |
| 6V5215 | 22 BOLT (M8X1.25X16-MM) | 1 | |
| 6V5221 | 23 BOLT (M8X1.25X80-MM) | 2 | |
| 7X2619 | 24 BOLT (M6X1X10-MM) | 1 | |
| 8T0100 | 25 BOLT (M8X1.25X60-MM) | 1 | |
| 8T2396 | 26 BOLT (M6X1X60-MM) | 1 | |
| 9M1974 | 27 WASHER-HARD (8.8X16X2-MM THK) | 6 | |
| 9X8256 | 28 WASHER (6.6X12X2-MM THK) | 3 | |
| 2886817 | 29 SENSOR AS-TEMPERATURE (EXHAUST) | 1 | |
| 2886820 | 30 SENSOR AS-TEMPERATURE (EXHAUST) | 1 |
