System And Components
317-7679 COMBUSTION GP-EXHAUSTPART OF 318-1119, 318-1120, 318-1158 COMBUSTION GP-EXHAUST
Group No: 317-7679
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 7 | |
| 2041611 | 2 STRAP-CABLE (DUAL) | 3 | |
| 2771873 | 3 CLIP (LADDER) | 1 | |
| 2856395 | 4 CLIP (LADDER) | 1 | |
| 2886817 | 5 SENSOR AS-TEMPERATURE (EXHAUST) | 1 | |
| 3341387 | 6 SENSOR-TEMPERATURE (FLAME DETECT, TURBO OUTLET) | 1 | |
| 2890728 | 7 NUT (M8X1.25-THD) | 2 | |
| 2893107 | 8 GASKET | 1 | |
| 2903930 | 9 BOLT (M8X1.25X55-MM) | 2 | |
| 2916641 | 10 CLIP | 1 | |
| 2952713 | 11 TUBE AS | 1 | |
| 2953099 | 12 SPARK PLUG | 1 | |
| 2956240 | 13 WIRE AS | 1 | |
| 3008688 | 14 CLAMP-BAND | 1 | |
| 3053020 | 15 BRACKET AS | 1 | |
| 8T2321 | NUT-WELD (M8X1.25-THD) | 1 | |
| 3067473 | 16 SUPPORT AS | 1 | |
| 3150225 | 17 CLAMP-WIRE | 1 | |
| 3177659 | 18 COMBUSTION GP-EXHAUST | 1 | |
| 3183132 | 19 WIRE AS (NOZZLE HEATER) | 1 | |
| 1325789 | 20 CLIP (LADDER) | 1 | |
| 2901993 | 21 STRAP-CABLE | 3 | |
| 3E4352 | 22 WASHER-HARD (8.8X20.5X2.5-MM THK) | 4 | |
| 3T0849 | 23 BOLT-SOCKET HEAD (M6X1X25-MM) | 1 | |
| 5P7970 | 24 NUT (M8X1.25-THD) | 2 | |
| 6V5215 | 25 BOLT (M8X1.25X16-MM) | 1 | |
| 6V5221 | 26 BOLT (M8X1.25X80-MM) | 3 | |
| 7X2619 | 27 BOLT (M6X1X10-MM) | 1 | |
| 8T2396 | 28 BOLT (M6X1X60-MM) | 1 | |
| 8T9405 | 29 BOLT-SOCKET HEAD (M4X0.7X16-MM) | 1 | |
| 9M1974 | 30 WASHER-HARD (8.8X16X2-MM THK) | 6 | |
| 9X8256 | 31 WASHER (6.6X12X2-MM THK) | 3 |
