System And Components
337-5076 COMBUSTION GP-EXHAUSTPART OF 339-4373 COMBUSTION GP-EXHAUST
Group No: 337-5076
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 6 | |
| 2041611 | 2 STRAP-CABLE (DUAL) | 3 | |
| 2771873 | 3 CLIP (LADDER) | 1 | |
| 2856395 | 4 CLIP (LADDER) | 1 | |
| 2890728 | 5 NUT (M8X1.25-THD) | 2 | |
| 2893107 | 6 GASKET | 1 | |
| 2893930 | 7 TUBE AS-AIR | 1 | |
| 2903930 | 8 BOLT (M8X1.25X55-MM) | 2 | |
| 2916641 | 9 CLIP | 1 | |
| 2953099 | 10 SPARK PLUG | 1 | |
| 2956240 | 11 WIRE AS | 1 | |
| 3008688 | 12 CLAMP-BAND | 1 | |
| 3053020 | 13 BRACKET AS | 1 | |
| 8T2321 | NUT-WELD (M8X1.25-THD) | 1 | |
| 3150225 | 14 CLAMP-WIRE | 1 | |
| 3183132 | 15 WIRE AS (NOZZLE HEATER) | 1 | |
| 3S2093 | STRAP-CABLE | 1 | |
| 8T8737 | PLUG-SEAL | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 1 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 1 | |
| 2830055 | ADAPTER-CONNECTOR | 2 | |
| 2901993 | STRAP-CABLE | 1 | |
| 3177377 | CONNECTOR AS | 1 | |
| 9N1756 | SEAL-O-RING | 1 | |
| 3170808 | SEAL-O-RING | 2 | |
| 3217276 | SLEEVE (81-CM) | ||
| 3284158 | 16 SUPPORT AS | 1 | |
| 3341387 | 17 SENSOR-TEMPERATURE (EXHAUST) | 1 | |
| 3375078 | 18 COMBUSTION GP-EXHAUST | 1 | |
| 1325789 | 19 CLIP (LADDER) | 1 | |
| 2901993 | 20 STRAP-CABLE | 4 | |
| 3E4352 | 21 WASHER-HARD (8.8X20.5X2.5-MM THK) | 4 | |
| 5P7970 | 22 NUT (M8X1.25-THD) | 2 | |
| 6V5217 | 23 BOLT (M8X1.25X20-MM) | 1 | |
| 6V5221 | 24 BOLT (M8X1.25X80-MM) | 3 | |
| 7X2619 | 25 BOLT (M6X1X10-MM) | 1 | |
| 8T8442 | 26 BOLT-SOCKET HEAD (M6X1X30-MM) | 2 | |
| 8T9405 | 27 BOLT-SOCKET HEAD (M4X0.7X16-MM) | 1 | |
| 9M1974 | 28 WASHER-HARD (8.8X16X2-MM THK) | 6 | |
| 9X8256 | 29 WASHER (6.6X12X2-MM THK) | 3 | |
| 2886817 | 31 SENSOR AS-TEMPERATURE (EXHAUST) | 1 |
