System And Components
280-9339 COMBUSTION GP-EXHAUSTS/N SDP516-UP
Group No: 280-9339
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1270929 | 1 CLAMP-V BAND | 1 | |
| 8T0122 | NUT-FULL (1/4-28-THD) | 1 | |
| 2840671 | 2 CLAMP-BAND | 1 | |
| 2790316 | 3 BRACKET-SUPPORT | 1 | |
| 2809347 | 4 COMBUSTION GP-EXHAUST | 1 | |
| 2820237 | 5 BODY GP-COMBUSTION (AFTERTREATMENT REGEN DEVICE) | 1 | |
| 2800586 | 6 TUBE AS | 1 | |
| 2840745 | 7 BOLT | 2 | |
| 2840744 | 8 BOLT (3/8-16X14.29-IN) | 1 | |
| 2877635 | 9 WASHER (11X21X2.5-MM THK) | 4 | |
| 3M7045 | 10 PLUG (3/4-14 NPT-THD) | 1 | |
| 2840750 | 11 WASHER (10.2X18.5X2.5-MM THK) | 3 | |
| 5M6214 | 12 PLUG (1/8-27 PTF) | 1 | |
| 2895010 | 13 NUT (M10X1.25-THD) | 2 | |
| 2877632 | 14 BOLT (M10X1.5X45-MM) | 2 |
