System And Components
289-2744 COMBUSTION GP-EXHAUSTS/N SDP4642-5792
Group No: 289-2744
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 6 | |
| 2953099 | 2 SPARK PLUG (AFTERTREATMENT REGEN DEVICE) | 1 | |
| 2840671 | 3 CLAMP-BAND | 1 | |
| 2856393 | 4 CLIP (LADDER) | 2 | |
| 2856395 | 5 CLIP (LADDER) | 2 | |
| 2956239 | 6 WIRE AS-IGNITION | 1 | |
| 2890728 | 7 NUT (M8X1.25-THD) | 2 | |
| 2893107 | 8 GASKET | 1 | |
| 2900113 | 9 CLIP | 1 | |
| 2901479 | 10 SUPPORT AS | 1 | |
| 3003723 | 11 COMBUSTION GP-EXHAUST | 1 | |
| 2903930 | 12 BOLT (M8X1.25X55-MM) | 2 | |
| 2919949 | 15 TUBE AS-AIR | 1 | |
| 0S1594 | 16 BOLT (3/8-16X1-IN) | 1 | |
| 0T0573 | 17 BOLT (3/8-16X2.75-IN) | 1 | |
| 4P7581 | 18 CLIP (LADDER) | 1 | |
| 2901993 | 21 STRAP-CABLE | 3 | |
| 2041611 | 22 STRAP-CABLE (DUAL) | 2 | |
| 5M2894 | 24 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 3T0849 | 25 BOLT-SOCKET HEAD (M6X1X25-MM) | 2 | |
| 7X2619 | 26 BOLT (M6X1X10-MM) | 1 | |
| 9X8256 | 28 WASHER (6.6X12X2-MM THK) | 3 | |
| 2886818 | 29 SENSOR-TEMPERATURE | 1 | |
| 2886820 | 30 SENSOR AS-TEMPERATURE | 1 | |
| 3E4352 | 31 WASHER-HARD (8.8X20.5X2.5-MM THK) | 4 | |
| 0L1351 | 32 BOLT (3/8-16X0.875-IN) | 2 | |
| 6V8189 | 33 NUT (5/16-18-THD) | 1 | |
| 8T4896 | 34 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 9M1974 | 35 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 2351088 | 36 NUT (3/8-16-THD) | 1 |
