System And Components
320-2229 COMBUSTION GP-EXHAUSTS/N SDP1-22497
Group No: 320-2229
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 4 | |
| 2041611 | 2 STRAP-CABLE (DUAL) | 2 | |
| 2840671 | 3 CLAMP-BAND | 1 | |
| 2856393 | 4 CLIP (LADDER) | 1 | |
| 2856395 | 5 CLIP (LADDER) | 1 | |
| 2886820 | 6 SENSOR AS-TEMPERATURE | 1 | |
| 2890728 | 7 NUT (M8X1.25-THD) | 2 | |
| 2893107 | 8 GASKET | 1 | |
| 2903930 | 9 BOLT (M8X1.25X55-MM) | 2 | |
| 2911832 | 10 CLIP | 1 | |
| 2911833 | 11 CLIP | 1 | |
| 2953099 | 12 SPARK PLUG | 1 | |
| 3001946 | 13 TUBE AS | 1 | |
| 3006608 | 14 SUPPORT AS | 1 | |
| 3150225 | 15 CLAMP-WIRE | 1 | |
| 3183133 | 16 WIRE AS (NOZZLE HEATER) | 1 | |
| 3202226 | 17 COMBUSTION GP-EXHAUST | 1 | |
| 0S1619 | 18 BOLT (3/8-16X3-IN) | 1 | |
| 1A2029 | 19 BOLT (3/8-16X1.125-IN) | 1 | |
| 2901993 | 20 STRAP-CABLE | 5 | |
| 2956234 | 21 WIRE AS | 1 | |
| 2961406 | 22 SENSOR-TEMPERATURE | 1 | |
| 3E4352 | 23 WASHER-HARD (8.8X20.5X2.5-MM THK) | 4 | |
| 3T0849 | 24 BOLT-SOCKET HEAD (M6X1X25-MM) | 2 | |
| 4P7581 | 25 CLIP (LADDER) | 1 | |
| 5K0906 | 26 BOLT (5/16-18X0.625-IN) | 1 | |
| 0L1351 | 27 BOLT (3/8-16X0.875-IN) | 1 | |
| 7X2619 | 28 BOLT (M6X1X10-MM) | 1 | |
| 8T0639 | 29 BOLT (M6X1X12-MM) | 1 | |
| 8T4224 | 30 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 8T9405 | 31 BOLT-SOCKET HEAD (M4X0.7X16-MM) | 1 | |
| 9M1974 | 32 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 9X8256 | 33 WASHER (6.6X12X2-MM THK) | 3 | |
| 9X8267 | 34 WASHER (6.6X12X2-MM THK) | 1 | |
| 8T4896 | 35 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 |
