System And Components
320-7669 COMBUSTION GP-EXHAUSTS/N SDP22498-UP
Group No: 320-7669
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 7 | |
| 1108330 | 2 SPACER (11.3X19.05X90-MM THK) | 1 | |
| 1976453 | 3 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 2041611 | 4 STRAP-CABLE (DUAL) | 1 | |
| 2351088 | 5 NUT (3/8-16-THD) | 3 | |
| 2840671 | 6 CLAMP-BAND | 1 | |
| 2856393 | 7 CLIP (LADDER) | 2 | |
| 2856395 | 8 CLIP (LADDER) | 3 | |
| 2886818 | 9 SENSOR-TEMPERATURE (EXHAUST) | 1 | |
| 3341387 | 10 SENSOR-TEMPERATURE (EXHAUST) | 1 | |
| 2890728 | 11 NUT (M8X1.25-THD) | 2 | |
| 2893107 | 12 GASKET | 1 | |
| 2903930 | 13 BOLT (M8X1.25X55-MM) | 2 | |
| 2953099 | 14 SPARK PLUG (AFTERTREATMENT REGEN DEVICE) | 1 | |
| 3014126 | 15 SUPPORT AS | 1 | |
| 3038533 | 16 TUBE AS | 1 | |
| 3150225 | 17 CLAMP-WIRE | 1 | |
| 3183134 | 18 WIRE AS (NOZZLE HEATER) | 1 | |
| 3207670 | 19 COMBUSTION GP-EXHAUST | 1 | |
| 0T0102 | 20 BOLT (3/8-16X0.625-IN) | 2 | |
| 1A5964 | 21 BOLT (3/8-16X4.5-IN) | 1 | |
| 1B2578 | 22 NUT (3/8-16-THD) | 1 | |
| 2901993 | 23 STRAP-CABLE | 5 | |
| 2956240 | 24 WIRE AS | 1 | |
| 3E4352 | 25 WASHER-HARD (8.8X20.5X2.5-MM THK) | 4 | |
| 3T0849 | 26 BOLT-SOCKET HEAD (M6X1X25-MM) | 2 | |
| 4P7581 | 27 CLIP (LADDER) | 1 | |
| 5M2894 | 28 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 6V5839 | 29 WASHER (11X21X2.5-MM THK) | 1 | |
| 6V6317 | 30 BOLT (M10X1.5X20-MM) | 1 | |
| 6V8189 | 31 NUT (5/16-18-THD) | 1 | |
| 7X2619 | 32 BOLT (M6X1X10-MM) | 1 | |
| 8T9405 | 33 BOLT-SOCKET HEAD (M4X0.7X16-MM) | 1 | |
| 9M1974 | 34 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 9X8256 | 35 WASHER (6.6X12X2-MM THK) | 3 |
