System And Components
257-9145 COVER GP-CYLINDER BLOCKS/N C7C155-99999
Group No: 257-9145
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W6544 | 1 COVER | 1 | |
| 4P5918 | 2 CLIP | 3 | |
| 3424977 | 3 COVER-SIDE | 2 | |
| 7W3872 | 4 SLEEVE (MARKED X) | 6 | |
| 9X2099 | 5 STUD (M8X1.25X52.75-MM) | 1 | |
| 1107618 | 6 BOLT AS | 3 | |
| 2495523 | 7 COVER-SIDE (BREATHER) | 1 | |
| 5C7261 | 8 NUT (M8X1.25-THD) | 3 | |
| 8T4224 | 9 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 9M1974 | 10 WASHER-HARD (8.8X16X2-MM THK) | 24 | |
| 4Y9652 | 11 GASKET (SIDE COVER) | 2 | |
| 3713481 | 12 GASKET (BREATHER) | 1 | |
| 2103321 | 13 STUD (M8X1.25-THD) | 3 | |
| 6V2317 | 14 BOLT (M8X1.25X30-MM) | 21 | |
| 1U8846 | 15 SEALANT-GASKET | ||
| 3711607 | 16 PLATE | 1 | |
| 1504086 | 17 SCREW (M4X0.7X16-MM) | 2 |
