System And Components
288-3778 BASE GP-VALVE COVER & INJ HARNS/N S3C150-UP
Group No: 288-3778
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1801538 | 1 DOWEL | 2 | |
| 2396248 | 2 VALVE GP-CHECK (ENGINE OIL) | 1 | |
| 2562209 | 3 SEAL | 3 | |
| 2720389 | 4 SEAL | 1 | |
| 2859259 | 5 SENSOR GP-PRESSURE (ENGINE OIL) | 1 | |
| 2887035 | 6 BASE-VALVE MECHANISM COVER | 1 | |
| 3281024 | 7 BREATHER AS (CRANKCASE) | 1 | |
| 2892088 | 8 SEAL | 1 | |
| 2893661 | 9 SEAL | 1 | |
| 2912900 | 10 ADAPTER GP-BREATHER (CRANKCASE) | 1 | |
| 1J9671 | 11 SEAL-O-RING | 3 | |
| 2113445 | 12 STUD (M8X1.25X75-MM) | 8 | |
| 1488409 | 13 PLUG AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 9S8008 | PLUG (1-1/16-12-THD) | 1 | |
| 6V3918 | 14 BOLT (M8X1.25X50-MM) | 6 | |
| 7J0204 | 15 SEAL-O-RING | 1 | |
| 7L9061 | 16 SEAL-O-RING | 1 | |
| 9M1974 | 17 WASHER-HARD (8.8X16X2-MM THK) | 14 | |
| 9S8003 | 18 PLUG (1/2-20-THD) | 3 | |
| 9S8007 | 19 PLUG (3/8-24-THD) | 1 |
