System And Components
317-7670 COMBUSTION GP-EXHAUSTS/N S3C150-UP
Group No: 317-7670
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 5 | |
| 2041611 | 2 STRAP-CABLE (DUAL) | 2 | |
| 2771873 | 3 CLIP (LADDER) | 2 | |
| 2886818 | 4 SENSOR-TEMPERATURE (FLAME BOUNDARY, EXHAUST 3) | 1 | |
| 3341387 | 5 SENSOR-TEMPERATURE (FLAME DETECT, TURBO OUTLET) | 1 | |
| 2890728 | 6 NUT (M8X1.25-THD) | 2 | |
| 2893107 | 7 GASKET | 1 | |
| 2901392 | 8 SUPPORT AS | 1 | |
| 2902102 | 9 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 1 | |
| 2903930 | 10 BOLT (M8X1.25X55-MM) | 2 | |
| 2916641 | 11 CLIP | 1 | |
| 2919951 | 12 TUBE AS | 1 | |
| 2953099 | 13 SPARK PLUG | 1 | |
| 3008688 | 14 CLAMP-BAND | 1 | |
| 3150225 | 15 CLAMP-WIRE | 1 | |
| 3177650 | 16 COMBUSTION GP-EXHAUST | 1 | |
| 3183134 | 17 WIRE AS (NOZZLE HEATER) | 1 | |
| 2901993 | 18 STRAP-CABLE | 3 | |
| 2956240 | 19 WIRE AS | 1 | |
| 3E4352 | 20 WASHER-HARD (8.8X20.5X2.5-MM THK) | 4 | |
| 3T0849 | 21 BOLT-SOCKET HEAD (M6X1X25-MM) | 2 | |
| 5M2894 | 22 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 5P7970 | 23 NUT (M8X1.25-THD) | 2 | |
| 6V5215 | 24 BOLT (M8X1.25X16-MM) | 1 | |
| 6V5222 | 25 BOLT (M8X1.25X85-MM) | 2 | |
| 7X2619 | 26 BOLT (M6X1X10-MM) | 1 | |
| 8T9405 | 27 BOLT-SOCKET HEAD (M4X0.7X16-MM) | 1 | |
| 9M1974 | 28 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 9X8256 | 29 WASHER (6.6X12X2-MM THK) | 3 |
