System And Components
289-2734 COMBUSTION GP-EXHAUSTS/N B5R1-150
Group No: 289-2734
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 4 | |
| 1108330 | 2 SPACER (11.3X19.05X90-MM THK) | 1 | |
| 1976453 | 3 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 2775439 | 4 SPARK PLUG (ARD) | 1 | |
| 2782449 | 5 GASKET | 1 | |
| 2840671 | 6 CLAMP-BAND | 1 | |
| 2856393 | 7 CLIP (LADDER) | 2 | |
| 2856395 | 8 CLIP (LADDER) | 5 | |
| 2867949 | 9 WIRE AS-IGNITION | 1 | |
| 2681669 | WIRE-IGNITION (PLUG) | 1 | |
| 2841492 | SLEEVE (122-CM) | ||
| 2867941 | WIRE AS-GROUND | 1 | |
| 2890728 | 10 NUT (M8X1.25-THD) | 2 | |
| 2893916 | 11 TUBE AS | 1 | |
| 2900113 | 12 CLIP | 1 | |
| 2901477 | 13 SUPPORT AS | 1 | |
| 2901695 | 14 COMBUSTION GP-EXHAUST | 1 | |
| 2903930 | 15 BOLT (M8X1.25X55-MM) | 2 | |
| 2911832 | 16 CLIP | 1 | |
| 2911833 | 17 CLIP | 1 | |
| 1089656 | 18 STRAP-CABLE | 3 | |
| 1705632 | 19 BOLT (M4X0.7X16-MM) | 1 | |
| 2046102 | 20 WASHER-HARD (4.45X9.52X1-MM THK) | 1 | |
| 2901993 | 21 STRAP-CABLE | 4 | |
| 1A5964 | 22 BOLT (3/8-16X4.5-IN) | 1 | |
| 4P7581 | 23 CLIP (LADDER) | 1 | |
| 4P8134 | 24 CLIP (LADDER) | 1 | |
| 5K0906 | 25 BOLT (5/16-18X0.625-IN) | 1 | |
| 5M2894 | 26 WASHER-HARD (10.2X18.5X2.5-MM THK) | 5 | |
| 6V5839 | 27 WASHER (11X21X2.5-MM THK) | 1 | |
| 6V6317 | 28 BOLT (M10X1.5X20-MM) | 1 | |
| 6V8490 | 29 BOLT (M6X1X25-MM) | 2 | |
| 7X2619 | 30 BOLT (M6X1X10-MM) | 1 | |
| 8T4224 | 31 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 9X8256 | 32 WASHER (6.6X12X2-MM THK) | 3 | |
| 2886813 | 33 SENSOR GP-TEMPERATURE (EXHAUST) | 1 | |
| 2886819 | 34 SENSOR GP-TEMPERATURE (EXHAUST) | 1 |
