System And Components
185-3442 LINES GP-DIVERTER VALVES/N W6A1-UP
Group No: 185-3442 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3477715 | 1 FITTING GP-HYDRAULIC (QUICK DISCONNECT) | 2 | |
| 1348221 | 3 BOLT (M10X1.5X120-MM) | 4 | |
| 2909591 | 4 VALVE GP-DIVERTER (BOOM CYL, HEAD END) | 1 | |
| 1518866 | 5 ELBOW | 2 | |
| 2909589 | 6 VALVE GP-DIVERTER (BOOM CYL, ROD END) | 1 | |
| 1965381 | 7 HOSE AS | 1 | |
| 2013956 | 8 HOSE AS | 1 | |
| 2013957 | 9 HOSE AS | 1 | |
| 2013958 | 10 HOSE AS | 1 | |
| 1P3702 | 11 SEAL-RECTANGULAR | 4 | |
| 4J5267 | 12 SEAL-O-RING | 2 | |
| 6V9746 | 13 SEAL-O-RING | 2 | |
| 8T6685 | 14 BOLT (M10X1.5X110-MM) | 4 | |
| 2802747 | 15 BOLT-SOCKET HEAD (M10X1.5X60-MM) | 4 | |
| 8T4121 | 16 WASHER-HARD (11X21X2.5-MM THK) | 16 | |
| 8T4182 | 17 BOLT (M10X1.5X45-MM) | 16 | |
| 8T9403 | 18 FLANGE-HALF | 8 | |
| 1017398 | 19 BOLT-SOCKET HEAD (M10X1.5X40-MM) | 8 |
