System And Components
321-0553 LINES GP-RIDE CONTROL -VARIABLE ADJUSTABLE BOOMS/N W8P1-UP
Group No: 321-0553
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1017403 | 1 BOLT-SOCKET HEAD (M10X1.5X80-MM) | 8 | |
| 1167286 | 2 CLAMP-SINGLE | 1 | |
| 1949390 | 3 CLAMP GP-HYDRAULIC LINES | 2 | |
| 1949388 | CLAMP | 2 | |
| 1949389 | PLATE | 1 | |
| 3304669 | 4 TUBE AS | 1 | |
| 2146863 | 5 SENSOR GP-PRESSURE (RIDE CONTROL) | 1 | |
| 3292227 | 6 TUBE AS | 1 | |
| 2877334 | 7 FLANGE | 1 | |
| 2957688 | 8 VALVE GP-SOLENOID (RIDE CONTROL , HEAD END, LH) | 1 | |
| 2957689 | 9 VALVE GP-SOLENOID (RIDE CONTROL , HEAD END, RH) | 1 | |
| 2958554 | 10 BLOCK | 1 | |
| 2959705 | 11 CLAMP AS | 1 | |
| 2993657 | 12 CLAMP | 2 | |
| 2993659 | 13 VALVE GP-SOLENOID (RIDE CONTROL) | 1 | |
| 3055899 | 14 SPACER | 2 | |
| 3105053 | 15 HOSE AS | 1 | |
| 3173663 | 16 BRACKET | 1 | |
| 1017404 | 17 BOLT-SOCKET HEAD (M10X1.5X30-MM) | 4 | |
| 1053478 | 18 BOLT-SOCKET HEAD (M10X1.5X35-MM) | 4 | |
| 1488341 | 19 CONNECTOR AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8713 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1536256 | 20 ELBOW AS | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 8C7563 | ELBOW | 1 | |
| 1646872 | 21 TEE AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 1158634 | TEE-O-RING | 1 | |
| 1980143 | 22 ELBOW AS | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1572348 | ELBOW | 1 | |
| 1P3703 | 23 SEAL-RECTANGULAR | 1 | |
| 2717649 | 24 BOLT (M10X1.5X95-MM) | 2 | |
| 2939452 | 25 MOUNTING-CABLE TIE | 1 | |
| 2978107 | 26 BOLT (M10X1.5X105-MM) | 1 | |
| 3J1907 | 27 SEAL-O-RING | 1 | |
| 3S2093 | 28 STRAP-CABLE | 3 | |
| 4J5267 | 29 SEAL-O-RING | 1 | |
| 6V9746 | 30 SEAL-O-RING | 2 | |
| 8T3844 | 31 BOLT (M6X1X70-MM) | 3 | |
| 8T4121 | 32 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T4133 | 33 NUT (M10X1.5-THD) | 1 | |
| 8T4136 | 34 BOLT (M10X1.5X25-MM) | 1 | |
| 8T6685 | 35 BOLT (M10X1.5X110-MM) | 1 | |
| 8T6868 | 36 BOLT (M12X1.75X80-MM) | 4 | |
| 8T6974 | 37 BOLT (M6X1X80-MM) | 1 | |
| 9X8256 | 38 WASHER (6.6X12X2-MM THK) | 1 | |
| 2031912 | 39 HOSE AS | 2 | |
| 3193769 | 40 ACCUMULATOR GP (CHARGED) | 2 |
