System And Components
251-8015 LINES GP-BOOM -ACCUMULATORS/N W2S5076-UP
Group No: 251-8015 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1053477 | 1 BOLT-SOCKET HEAD (M10X1.5X45-MM) | 16 | |
| 1374199 | 2 TUBE AS | 1 | |
| 1391942 | 3 HOSE AS | 1 | |
| 1394016 | 4 INSERT-RUBBER | 2 | |
| 1457166 | 5 VALVE GP-MANUAL (BOOM LOWERING CONTROL) | 1 | |
| 1488440 | 6 TEE AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 8C0569 | TEE-O-RING | 1 | |
| 1521267 | 7 ELBOW | 1 | |
| 3304679 | 8 TUBE AS | 1 | |
| 1621415 | 9 HOSE AS | 1 | |
| 1949390 | 10 CLAMP GP-HYDRAULIC LINES | 2 | |
| 1949388 | CLAMP | 2 | |
| 1949389 | PLATE | 1 | |
| 2006181 | 11 PLATE AS | 1 | |
| 2090592 | 12 CLAMP AS | 1 | |
| 2090593 | 13 CLAMP AS | 1 | |
| 2104782 | 14 PLATE AS | 1 | |
| 2126760 | 15 HOSE AS | 1 | |
| 2126761 | 16 HOSE AS | 1 | |
| 2126764 | 17 HOSE AS | 1 | |
| 2126765 | 18 HOSE AS | 1 | |
| 2126766 | 19 HOSE AS | 1 | |
| 2263437 | 20 HOSE AS | 1 | |
| 2268353 | 21 HOSE AS | 1 | |
| 2883658 | 22 CLAMP-SINGLE | 1 | |
| 2993658 | 23 CLAMP | 4 | |
| 3055900 | 24 SPACER | 4 | |
| 3535950 | 25 HOSE AS | 1 | |
| 3535954 | 26 ACCUMULATOR GP-HYDRAULIC (CHARGED) | 2 | |
| 3535955 | 27 ORIFICE | 1 | |
| 1017404 | 28 BOLT-SOCKET HEAD (M10X1.5X30-MM) | 4 | |
| 1395751 | 29 CLAMP-SINGLE | 2 | |
| 1407599 | 30 CLAMP | 1 | |
| 1488315 | 31 CONNECTOR AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8642 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488336 | 32 CONNECTOR AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1488341 | 33 CONNECTOR AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8713 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488390 | 34 ELBOW AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8626 | ELBOW | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488433 | 35 TEE AS | 2 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V9836 | TEE-SWIVEL | 1 | |
| 1488435 | 36 TEE AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8781 | TEE | 1 | |
| 1488446 | 37 TEE AS-SWIVEL | 1 | |
| 6V9838 | TEE-SWIVEL | 1 | |
| 7J9108 | SEAL-O-RING | 2 | |
| 1536237 | 38 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9004 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1649869 | 39 CONNECTOR AS | 3 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 9X2297 | CONNECTOR | 1 | |
| 1P3702 | 40 SEAL-RECTANGULAR | 4 | |
| 1P3703 | 41 SEAL-RECTANGULAR | 2 | |
| 2542675 | 42 VALVE GP-LOAD CONTROL | 2 | |
| 2808912 | 43 BOLT (M10X1.5X75-MM) | 2 | |
| 3J1907 | 44 SEAL-O-RING | 1 | |
| 4J5267 | 45 SEAL-O-RING | 3 | |
| 5K9090 | 46 SEAL-O-RING | 2 | |
| 5P7468 | 47 CLIP (SLOT) | 2 | |
| 5P7469 | 48 CLIP (TAB) | 2 | |
| 5P8444 | 49 GROMMET (37-MM ID) | 2 | |
| 6V0400 | 50 FLANGE-HALF | 4 | |
| 6V8397 | 51 SEAL-O-RING | 2 | |
| 8C8451 | 52 BOLT (M6X1X40-MM) | 4 | |
| 8T4121 | 53 WASHER-HARD (11X21X2.5-MM THK) | 16 | |
| 8T4171 | 54 BOLT (M6X1X12-MM) | 2 | |
| 8T4172 | 55 BOLT (M10X1.5X80-MM) | 2 | |
| 8T4182 | 56 BOLT (M10X1.5X45-MM) | 8 | |
| 8T4184 | 57 BOLT (M12X1.75X45-MM) | 8 | |
| 8T4185 | 58 BOLT (M10X1.5X50-MM) | 2 | |
| 8T4223 | 59 WASHER-HARD (13.5X25.5X3-MM THK) | 10 | |
| 8T4956 | 60 BOLT (M12X1.75X35-MM) | 2 | |
| 8T5005 | 61 BOLT (M10X1.5X70-MM) | 2 | |
| 8T9403 | 62 FLANGE-HALF | 8 | |
| 7K1181 | 63 STRAP-CABLE | 8 | |
| 2347783 | 64 HOSE AS | 2 |
