System And Components
185-3441 VALVE & LINES GP-DIVERTERS/N W3H1-UP
Group No: 185-3441
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3477715 | 1 FITTING GP-HYDRAULIC (QUICK DISCONNECT) | 2 | |
| 1017398 | 3 BOLT-SOCKET HEAD (M10X1.5X40-MM) | 8 | |
| 1348221 | 4 BOLT (M10X1.5X120-MM) | 4 | |
| 2909591 | 5 VALVE GP-DIVERTER (BOOM CYL, HEAD END) | 1 | |
| 1518866 | 6 ELBOW | 2 | |
| 2909589 | 7 VALVE GP-DIVERTER (BOOM CYL, ROD END) | 1 | |
| 1856818 | 8 HOSE AS | 1 | |
| 8T6685 | 9 BOLT (M10X1.5X110-MM) | 4 | |
| 2004055 | 10 HOSE AS | 1 | |
| 2013957 | 11 HOSE AS | 1 | |
| 2013958 | 12 HOSE AS | 1 | |
| 1P3702 | 13 SEAL-RECTANGULAR | 4 | |
| 4J5267 | 14 SEAL-O-RING | 2 | |
| 6V9746 | 15 SEAL-O-RING | 2 | |
| 2802747 | 16 BOLT-SOCKET HEAD (M10X1.5X60-MM) | 4 | |
| 8T4121 | 17 WASHER-HARD (11X21X2.5-MM THK) | 16 | |
| 8T4182 | 18 BOLT (M10X1.5X45-MM) | 16 | |
| 8T9403 | 19 FLANGE-HALF | 8 |
