Assembly
100%

350-6985 FRAME GP-UNDERCARRIAGE -HEAVY-DUTYS/N GHS1-UP; MLW1-UP

Group No: 350-6985
Part NumberPart NameQty
19015461 IDLER GP-TRACK4
19670742 STRIP-WEAR (REAR)4
19670783 STRIP-WEAR (FRONT)4
20463654 SPACER (15-MM THK)12
20561645 GUIDE AS2
25500456 CAP GP-TRACK IDLER (REAR, RH)2
26827417 SCRAPER2
26904878 CAP GP-TRACK IDLER (FRONT, RH, LH)4
35151149 FRAME GP-TRACK ROLLER (HEAVY-DUTY, SYSTEMONE)1
358723910 ROLLER GP-TRACK-SINGLE FLANGE8
358858311 ROLLER GP-TRACK-DOUBLE FLANGE8
255004612 CAP GP-TRACK IDLER (REAR, LH)2
8T414013 BOLT (M16X2X60-MM)12
8T418314 BOLT (M12X1.75X40-MM)4
8T419215 BOLT (M12X1.75X25-MM)24
8T422316 WASHER-HARD (13.5X25.5X3-MM THK)28
