System And Components
289-2724 COMBUSTION GP-EXHAUSTS/N LEE3806-6850
Group No: 289-2724
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 6 | |
| 2041611 | 2 STRAP-CABLE (DUAL) | 1 | |
| 2771873 | 3 CLIP (LADDER) | 2 | |
| 2856393 | 4 CLIP (LADDER) | 1 | |
| 2890728 | 5 NUT (M8X1.25-THD) | 2 | |
| 2893107 | 6 GASKET | 1 | |
| 2900113 | 7 CLIP | 1 | |
| 2901475 | 8 SUPPORT AS | 1 | |
| 2902102 | 9 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 1 | |
| 2903930 | 10 BOLT (M8X1.25X55-MM) | 2 | |
| 2916641 | 11 CLIP | 1 | |
| 2953099 | 12 SPARK PLUG (ARD) | 1 | |
| 2954332 | 13 TUBE AS | 1 | |
| 3003737 | 14 COMBUSTION GP-EXHAUST | 1 | |
| 3008688 | 15 CLAMP-BAND | 1 | |
| 1325789 | 16 CLIP (LADDER) | 1 | |
| 2901993 | 17 STRAP-CABLE | 4 | |
| 2956240 | 18 WIRE AS | 1 | |
| 3E4352 | 19 WASHER-HARD (8.8X20.5X2.5-MM THK) | 4 | |
| 3T0849 | 20 BOLT-SOCKET HEAD (M6X1X25-MM) | 2 | |
| 4P7428 | 21 CLIP (LADDER) | 1 | |
| 5P4116 | 22 WASHER-HARD (8.8X20.5X2-MM THK) | 1 | |
| 5P7970 | 23 NUT (M8X1.25-THD) | 2 | |
| 5P8245 | 24 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 6V5215 | 25 BOLT (M8X1.25X16-MM) | 1 | |
| 7X2619 | 26 BOLT (M6X1X10-MM) | 1 | |
| 6V5219 | 27 BOLT (M8X1.25X40-MM) | 3 | |
| 8T0293 | 28 BOLT (M12X1.75X20-MM) | 1 | |
| 9M1974 | 29 WASHER-HARD (8.8X16X2-MM THK) | 5 | |
| 9X8256 | 30 WASHER (6.6X12X2-MM THK) | 1 | |
| 9X8267 | 31 WASHER (6.6X12X2-MM THK) | 2 | |
| 2886817 | 32 SENSOR AS-TEMPERATURE (EXHAUST) | 1 | |
| 2886820 | 33 SENSOR AS-TEMPERATURE (EXHAUST) | 1 |
