Assembly
100%

319-7404 COMBUSTION GP-EXHAUSTS/N LEE1-UP

Group No: 319-7404
Part NumberPart NameQty
3S20931 STRAP-CABLE6
20416112 STRAP-CABLE (DUAL)2
27718733 CLIP (LADDER)1
28563954 CLIP (LADDER)1
28868185 SENSOR-TEMPERATURE1
28907286 NUT (M8X1.25-THD)2
28931077 GASKET1
29014608 SUPPORT AS1
29016879 COMBUSTION GP-EXHAUST1
290210210 BRACKET AS1
8T361210A NUT-WELD (M8X1.25-THD)1
290393011 BOLT (M8X1.25X55-MM)2
291664112 CLIP1
295309913 SPARK PLUG1
295624014 WIRE AS1
299532315 TUBE AS1
300868816 CLAMP-BAND1
319740517 SPACER (11X20X38.5-MM THK)1
290199318 STRAP-CABLE2
3E435219 WASHER-HARD (8.8X20.5X2.5-MM THK)6
3T084920 BOLT-SOCKET HEAD (M6X1X25-MM)2
4P742821 CLIP (LADDER)2
5P797022 NUT (M8X1.25-THD)1
5P824523 WASHER-HARD (13.5X25.5X3-MM THK)1
6V521524 BOLT (M8X1.25X16-MM)1
6V583925 WASHER (11X21X2.5-MM THK)1
6V821226 BOLT (M10X1.5X16-MM)1
7X261927 BOLT (M6X1X10-MM)1
8T029228 BOLT (M8X1.25X90-MM)2
8T029329 BOLT (M12X1.75X20-MM)1
9M197430 WASHER-HARD (8.8X16X2-MM THK)2
9X825631 WASHER (6.6X12X2-MM THK)1
9X826732 WASHER (6.6X12X2-MM THK)2
288682033 SENSOR AS-TEMPERATURE1
