System And Components
320-2803 COMBUSTION GP-EXHAUSTS/N LEE1-UP
Group No: 320-2803
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 5 | |
| 2041611 | 2 STRAP-CABLE (DUAL) | 2 | |
| 2771873 | 3 CLIP (LADDER) | 1 | |
| 2856395 | 4 CLIP (LADDER) | 1 | |
| 3341387 | 5 SENSOR-TEMPERATURE (FLAME DETECT, TURBO OUTLET) | 1 | |
| 2890728 | 6 NUT (M8X1.25-THD) | 2 | |
| 2893107 | 7 GASKET | 1 | |
| 2901460 | 8 SUPPORT AS | 1 | |
| 2902102 | 9 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 1 | |
| 2903930 | 10 BOLT (M8X1.25X55-MM) | 2 | |
| 2916641 | 11 CLIP | 1 | |
| 2953099 | 12 SPARK PLUG (AFTERTREATMENT REGEN DEVICE) | 1 | |
| 2956240 | 13 WIRE AS | 1 | |
| 2995323 | 14 TUBE AS | 1 | |
| 3008688 | 15 CLAMP-BAND | 1 | |
| 3150225 | 16 CLAMP-WIRE | 1 | |
| 3177657 | 17 COMBUSTION GP-EXHAUST | 1 | |
| 3183134 | 18 WIRE AS (NOZZLE HEATER) | 1 | |
| 3197405 | 19 SPACER (11X20X38.5-MM THK) | 1 | |
| 2901993 | 20 STRAP-CABLE | 2 | |
| 3E4352 | 21 WASHER-HARD (8.8X20.5X2.5-MM THK) | 6 | |
| 3T0849 | 22 BOLT-SOCKET HEAD (M6X1X25-MM) | 2 | |
| 4P7428 | 23 CLIP (LADDER) | 2 | |
| 5P7970 | 24 NUT (M8X1.25-THD) | 1 | |
| 5P8245 | 25 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 6V5215 | 26 BOLT (M8X1.25X16-MM) | 1 | |
| 6V5839 | 27 WASHER (11X21X2.5-MM THK) | 1 | |
| 6V8212 | 28 BOLT (M10X1.5X16-MM) | 1 | |
| 7X2619 | 29 BOLT (M6X1X10-MM) | 1 | |
| 8T0292 | 30 BOLT (M8X1.25X90-MM) | 2 | |
| 8T0293 | 31 BOLT (M12X1.75X20-MM) | 1 | |
| 8T9405 | 32 BOLT-SOCKET HEAD (M4X0.7X16-MM) | 1 | |
| 9M1974 | 33 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 9X8256 | 34 WASHER (6.6X12X2-MM THK) | 1 | |
| 9X8267 | 35 WASHER (6.6X12X2-MM THK) | 2 | |
| 2886818 | 36 SENSOR-TEMPERATURE | 1 |
