System And Components
289-7643 CONTROL GP-AIRS/N LEE1-606
Group No: 289-7643
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V9804 | 1 BOLT (M8X1.25X75-MM) | 3 | |
| 0307946 | 2 ELBOW | 3 | |
| 1501545 | 3 ELBOW | 1 | |
| 1554568 | 4 SPACER (11X20X8-MM THK) | 1 | |
| 1616963 | 5 CLAMP | 4 | |
| 2698788 | 6 CLAMP-BAND | 1 | |
| 2799691 | 7 HOSE | 2 | |
| 2807131 | 8 SENSOR GP-PRESSURE (DIFFERENTIAL) | 1 | |
| 2815842 | 9 UNION | 1 | |
| 2841134 | 10 CLIP | 1 | |
| 2873131 | 11 VALVE GP-AIR CONTROL (ARD COMBUSTION)(AIR PRESSURE CONTROL) | 1 | |
| 2877271 | 12 ADAPTER AS | 1 | |
| 2385078 | SEAL-O-RING | 1 | |
| 2877270 | ADAPTER | 1 | |
| 2888580 | 13 CLAMP-FUEL LINE | 1 | |
| 2888581 | 14 CLAMP-FUEL LINE | 3 | |
| 2891461 | 15 HOSE | 1 | |
| 2893108 | 16 GASKET | 1 | |
| 2897647 | 17 TUBE AS | 1 | |
| 2897648 | 18 TUBE AS | 1 | |
| 2897649 | 19 TUBE AS | 1 | |
| 2897650 | 20 TUBE AS | 1 | |
| 2897672 | 21 TUBE AS | 1 | |
| 2897682 | 22 TUBE AS | 1 | |
| 2897683 | 23 TUBE AS | 1 | |
| 2897687 | 24 BRACKET AS | 1 | |
| 2900113 | 25 CLIP | 3 | |
| 2906881 | 26 TUBE AS | 1 | |
| 2906883 | 27 TUBE AS | 1 | |
| 2N3680 | 29 SCREW-HEAD (1/4-20X0.75-IN) | 2 | |
| 5P0537 | 30 WASHER-HARD (7.2X14.5X2-MM THK) | 3 | |
| 6V5048 | 31 SEAL-O-RING | 3 | |
| 6V5049 | 32 SEAL-O-RING | 1 | |
| 6V5215 | 33 BOLT (M8X1.25X16-MM) | 2 | |
| 6V8214 | 34 BOLT (M6X1X20-MM) | 2 | |
| 7B2742 | 35 BOLT (1/4-20X1.25-IN) | 1 | |
| 8T4133 | 36 NUT (M10X1.5-THD) | 1 | |
| 9M1974 | 37 WASHER-HARD (8.8X16X2-MM THK) | 5 | |
| 9X8267 | 38 WASHER (6.6X12X2-MM THK) | 2 |
