System And Components
289-7643 CONTROL GP-AIRS/N LEE622-667
Group No: 289-7643
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V9804 | 1 BOLT (M8X1.25X75-MM) | 3 | |
| 0307946 | 2 ELBOW (90-DEG) | 2 | |
| 1616963 | 3 CLAMP | 4 | |
| 2698788 | 4 CLAMP-BAND | 1 | |
| 2799691 | 5 HOSE | 2 | |
| 2815842 | 6 UNION | 1 | |
| 2873131 | 7 VALVE GP-AIR CONTROL (ARD COMBUSTION)(AIR PRESSURE CONTROL) | 1 | |
| 2877271 | 8 ADAPTER AS | 1 | |
| 2877270 | ADAPTER | 1 | |
| 2385078 | 8A SEAL-O-RING | 1 | |
| 2886303 | 9 CLAMP-FUEL LINE | 2 | |
| 2888580 | 10 CLAMP-FUEL LINE | 5 | |
| 2888581 | 11 CLAMP-FUEL LINE | 1 | |
| 2891461 | 12 HOSE | 1 | |
| 2891474 | 13 SENSOR GP-PRESSURE (DIFFERENTIAL) | 1 | |
| 2893108 | 14 GASKET | 1 | |
| 2897672 | 15 TUBE AS | 1 | |
| 2897682 | 16 TUBE AS | 1 | |
| 2897683 | 17 TUBE AS | 1 | |
| 2897687 | 18 BRACKET AS | 1 | |
| 2900113 | 19 CLIP | 3 | |
| 2906881 | 20 TUBE AS | 1 | |
| 2906883 | 21 TUBE AS | 1 | |
| 2932399 | 22 BRACKET | 1 | |
| 2936516 | 23 BRACKET | 1 | |
| 2939092 | 24 TUBE AS | 1 | |
| 2939094 | 25 TUBE AS | 1 | |
| 2939095 | 26 TUBE AS | 1 | |
| 2939096 | 27 TUBE AS | 1 | |
| 0S1615 | 28 BOLT (1/4-20X0.75-IN) | 3 | |
| 2Y5829 | 29 NUT (M10X1.5-THD) | 1 | |
| 4F7957 | 30 BOLT (1/4-20X0.875-IN) | 2 | |
| 5P0537 | 31 WASHER-HARD (7.2X14.5X2-MM THK) | 6 | |
| 5P7970 | 32 NUT (M8X1.25-THD) | 1 | |
| 6V2315 | 33 BOLT (M6X1X35-MM) | 1 | |
| 6V5048 | 34 SEAL-O-RING | 4 | |
| 6V5215 | 35 BOLT (M8X1.25X16-MM) | 2 | |
| 6V5839 | 36 WASHER (11X21X2.5-MM THK) | 2 | |
| 6V8214 | 37 BOLT (M6X1X20-MM) | 2 | |
| 9M1974 | 38 WASHER-HARD (8.8X16X2-MM THK) | 6 | |
| 9S8002 | 39 PLUG (7/16-20-THD) | 2 | |
| 9X8267 | 40 WASHER (6.6X12X2-MM THK) | 2 |
