System And Components
232-5186 AIR COMPRESSOR GPS/N LGK7459-UP
Group No: 232-5186
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8R3600 | 1 ANGLE | 1 | |
| 2041611 | 2 STRAP-CABLE (DUAL) | 1 | |
| 2222889 | 3 BRACKET | 1 | |
| 2233505 | 4 SEAL | 1 | |
| 2350181 | 5 HOSE AS | 1 | |
| 2350182 | 6 HOSE AS | 1 | |
| 3042694 | 7 AIR COMPRESSOR GP | 1 | |
| 2898607 | 8 TUBE AS | 1 | |
| 3535129 | 9 ELBOW AS | 1 | |
| 6V3251 | SEAL-O-RING | 1 | |
| 0054173 | ELBOW | 1 | |
| 3438115 | 10 ELBOW AS | 1 | |
| 0307946 | ELBOW | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 3574571 | 11 ELBOW AS | 1 | |
| 6V6609 | SEAL-O-RING | 1 | |
| 1184728 | ELBOW | 1 | |
| 1B3057 | 12 CLIP | 1 | |
| 2Y5829 | 13 NUT (M10X1.5-THD) | 1 | |
| 4P7233 | 14 GROMMET | 1 | |
| 5P8245 | 15 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T1887 | 16 CLIP (SLOT) | 1 | |
| 8T1888 | 17 CLIP (TAB) | 1 | |
| 6V4248 | 18 BOLT (M10X1.5X25-MM) | 7 | |
| 6V5839 | 19 WASHER (11X21X2.5-MM THK) | 11 | |
| 6V6317 | 20 BOLT (M10X1.5X20-MM) | 1 | |
| 7B1598 | 22 CLIP | 1 | |
| 6V8197 | 23 BOLT (M12X1.75X40-MM) | 3 | |
| 3535130 | 24 ADAPTER AS | 2 | |
| 6V6609 | SEAL-O-RING | 1 | |
| 8M0505 | ADAPTER | 1 | |
| 7X0584 | 25 WASHER-HARD (13.5X20.5X2-MM THK) | 1 |
