System And Components
272-6655 AIR COMPRESSOR GPS/N LGK7400-UP
Group No: 272-6655
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3367700 | 1 CLAMP | 2 | |
| 6H7062 | 2 SPACER (13.5X25X19-MM THK) | 1 | |
| 6V4292 | 3 ELBOW | 1 | |
| 8R3600 | 4 ANGLE | 1 | |
| 2041611 | 5 STRAP-CABLE (DUAL) | 1 | |
| 2222889 | 6 BRACKET | 1 | |
| 2233505 | 7 SEAL | 1 | |
| 2350181 | 8 HOSE AS | 1 | |
| 2350182 | 9 HOSE AS | 1 | |
| 3042694 | 10 AIR COMPRESSOR GP | 1 | |
| 2726656 | 11 TUBE AS | 1 | |
| 3535129 | 12 ELBOW AS | 1 | |
| 6V3251 | SEAL-O-RING | 1 | |
| 0054173 | ELBOW | 1 | |
| 3438115 | 13 ELBOW AS | 1 | |
| 0307946 | ELBOW | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 1595255 | 14 ADAPTER | 1 | |
| 1B3057 | 15 CLIP | 1 | |
| 1B8471 | 16 CLIP | 1 | |
| 2Y5829 | 17 NUT (M10X1.5-THD) | 1 | |
| 8T1888 | 18 CLIP (TAB) | 1 | |
| 5P8245 | 19 WASHER-HARD (13.5X25.5X3-MM THK) | 3 | |
| 8T1887 | 20 CLIP (SLOT) | 1 | |
| 4P7233 | 21 GROMMET | 1 | |
| 6V4248 | 22 BOLT (M10X1.5X25-MM) | 5 | |
| 6V5839 | 23 WASHER (11X21X2.5-MM THK) | 9 | |
| 6V6317 | 24 BOLT (M10X1.5X20-MM) | 2 | |
| 6V6609 | 25 SEAL-O-RING | 2 | |
| 6V8197 | 26 BOLT (M12X1.75X40-MM) | 1 | |
| 3535130 | 27 ADAPTER AS | 2 | |
| 6V6609 | SEAL-O-RING | 1 | |
| 8M0505 | ADAPTER | 1 | |
| 3198815 | 28 HOSE (8-CM) | ||
| 7X0584 | 29 WASHER-HARD (13.5X20.5X2-MM THK) | 1 | |
| 7X3344 | 30 BOLT (M12X1.75X40-MM) | 3 |
