System And Components
351-2742 MOUNTING GP-ALTERNATOR & COMPRS/N LGK1-UP
Group No: 351-2742
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2432310 | 1 COVER | 2 | |
| 2792589 | 2 PULLEY AS-IDLER (8-GROOVE) | 2 | |
| 3331207 | 3 IDLER AS | 2 | |
| 3430768 | 4 BRACKET | 1 | |
| 3477963 | 5 TENSIONER-BELT | 1 | |
| 3639151 | 6 BRACKET-SUPPORT | 1 | |
| 5P8245 | 7 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 6V2317 | 8 BOLT (M8X1.25X30-MM) | 2 | |
| 6V5839 | 9 WASHER (11X21X2.5-MM THK) | 5 | |
| 6V5842 | 10 BOLT (M10X1.5X40-MM) | 4 | |
| 6V8149 | 11 NUT (M12X1.75-THD) | 2 | |
| 8T0644 | 12 BOLT (M10X1.5X90-MM) | 1 | |
| 8T0646 | 13 BOLT (M12X1.75X110-MM) | 4 | |
| 9M1974 | 14 WASHER-HARD (8.8X16X2-MM THK) | 2 |
