System And Components
244-8675 PAN GP-OIL -ENGINES/N LGK1-UP
Group No: 244-8675
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2101745 | 1 PAN-OIL | 1 | |
| 3503117 | 2 BELL AS-SUCTION | 1 | |
| 2101743 | 2A ELBOW | 1 | |
| 2173673 | 3 SEAL-ISOLATION (OIL PAN) | 1 | |
| 2173674 | 4 FASTENER AS | 14 | |
| 9X6451 | 5 PLUG-DRAIN (MAGNETIC)(ENGINE OIL PAN) | 2 | |
| 3893728 | 6 PLUG AS | 2 | |
| 2385084 | 6A SEAL-O-RING | 1 | |
| 2385084 | 6B SEAL-O-RING | 1 | |
| 3E8016 | 7 BOLT-SELF-LOCKING (M8X1.25X25-MM) | 2 | |
| 0619458 | 8 SEAL-O-RING (OIL PAN DRAIN PLUG) | 2 | |
| 5P8211 | 10 SEAL-O-RING | 1 | |
| 5P8245 | 11 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 6A5591 | 12 BOLT (M12X1.75X25-MM) | 4 | |
| 6N8863 | 13 WASHER (10.2X32X2.5-MM THK) | 14 | |
| 6V4249 | 14 BOLT (M10X1.5X50-MM) | 11 | |
| 9M1974 | 15 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 2873049 | 16 STUD (M10X1.5X50-MM) | 1 |
