System And Components
530-2297 BASE GP-OIL FILTERS/N LGK81008-UP
Group No: 530-2297
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4N8150 | 1 SPRING | 2 | |
| 7C3081 | 2 SPACER (6.88X9.53X50-MM THK) | 1 | |
| 7C3082 | 3 RETAINER | 1 | |
| 7C3083 | 4 SEAT-RELIEF VALVE SPRING | 1 | |
| 7C3954 | 5 SPRING AS | 1 | |
| 2243405 | 6 VALVE AS (OIL PUMP BYPASS) | 1 | |
| 2516668 | 7 BASE AS-OIL FILTER | 1 | |
| 2P4304 | STUD-HOLLOW | 1 | |
| 3B0623 | PLUG-CUP (25.73-MM OD) | 1 | |
| 3P1896 | PLUG-CUP (35.31-MM OD) | 2 | |
| 7W6390 | STUD-FILTER BASE | 1 | |
| 3196234 | 8 PLUG AS | 3 | |
| 9S9334 | PLUG (1-5/16-12-THD) | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3929208 | 9 PLUNGER-VALVE (RELIEF) | 2 | |
| 1833407 | 10 PLUG AS | 1 | |
| 9S8004 | PLUG (9/16-18-THD) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3218649 | 11 VALVE AS-FLUID SAMPLING (ENGINE OIL) | 1 | |
| 8C3446 | VALVE-SAMPLING (ENGINE OIL) | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 3683986 | 12 SPRING | 1 | |
| 6V8359 | 13 BOLT (M6X1X70-MM) | 1 | |
| 8C3445 | 14 CAP-DUST | 1 |
