System And Components
230-4523 COOLER GP-ENGINE OILS/N LGK1-UP
Group No: 230-4523
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1245043 | 1 COUPLING | 1 | |
| 1316645 | 2 HOSE | 1 | |
| 2242675 | 3 SEAL | 1 | |
| 3411429 | 4 SEAL | 2 | |
| 2304518 | 5 ELBOW | 1 | |
| 3493313 | 6 BONNET (OIL COOLER)(ENGINE) | 1 | |
| 3493311 | 7 BONNET (OIL COOLER)(ENGINE) | 1 | |
| 2368745 | 8 CORE AS-OIL COOLER (ENGINE) | 1 | |
| 3359214 | 9 CLAMP-BAND | 2 | |
| 2N5243 | 10 SEAL-O-RING | 2 | |
| 6V2317 | 11 BOLT (M8X1.25X30-MM) | 5 | |
| 6V3251 | 12 SEAL-O-RING | 2 | |
| 6V5063 | 13 SEAL-O-RING | 1 | |
| 6V5064 | 14 SEAL-O-RING | 3 | |
| 6V5219 | 15 BOLT (M8X1.25X40-MM) | 10 | |
| 6V5221 | 16 BOLT (M8X1.25X80-MM) | 1 | |
| 6V9027 | 17 SEAL-O-RING | 1 | |
| 9M1974 | 18 WASHER-HARD (8.8X16X2-MM THK) | 16 | |
| 9S8002 | 19 PLUG (7/16-20-THD) | 1 | |
| 9S8006 | 20 PLUG (7/8-14-THD) | 2 | |
| 9S8008 | 21 PLUG (1-1/16-12-THD) | 1 | |
| 9S9334 | 22 PLUG (1-5/16-12-THD) | 3 |
