System And Components
230-4523 COOLER GP-ENGINE OILS/N LGK1-UP
Group No: 230-4523
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1245043 | 1 COUPLING | 1 | |
| 1316645 | 2 HOSE | 1 | |
| 2242675 | 3 SEAL | 1 | |
| 4402907 | 4 ELBOW | 1 | |
| 3793436 | 5 CORE AS-OIL COOLER (ENGINE) | 1 | |
| 3359214 | 6 CLAMP-BAND | 2 | |
| 1173036 | 7 SEAL-O-RING | 1 | |
| 3601908 | 8 BONNET (OIL COOLER)(REAR) | 1 | |
| 3733187 | 9 BONNET-OIL COOLER (FRONT) | 1 | |
| 2N5243 | 10 SEAL-O-RING | 2 | |
| 6V2317 | 11 BOLT (M8X1.25X30-MM) | 10 | |
| 6V5219 | 12 BOLT (M8X1.25X40-MM) | 1 | |
| 6V5221 | 13 BOLT (M8X1.25X80-MM) | 1 | |
| 9M1974 | 14 WASHER-HARD (8.8X16X2-MM THK) | 12 | |
| 3048008 | 15 PLUG AS | 1 | |
| 6V9027 | SEAL-O-RING | 1 | |
| 9S8002 | PLUG (7/16-20-THD) | 1 | |
| 3535125 | 16 PLUG AS | 2 | |
| 6V3251 | SEAL-O-RING | 1 | |
| 9S8006 | PLUG (7/8-14-THD) | 1 | |
| 3535140 | 17 PLUG AS | 1 | |
| 6V5063 | SEAL-O-RING | 1 | |
| 9S8008 | PLUG (1-1/16-12-THD) | 1 | |
| 3535144 | 18 PLUG AS | 3 | |
| 6V5064 | SEAL-O-RING | 1 | |
| 9S9334 | PLUG (1-5/16-12-THD) | 1 | |
| 2139396 | 19 SEAL-O-RING | 1 |
