System And Components
231-0152 COOLER GP-ENGINE OILS/N LGK1-UP
Group No: 231-0152
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1316645 | 1 HOSE | 1 | |
| 2304518 | 2 ELBOW | 1 | |
| 2368745 | 3 CORE AS-OIL COOLER (ENGINE) | 1 | |
| 3411429 | 4 SEAL (FRONT) | 2 | |
| 3493313 | 5 BONNET (OIL COOLER) | 1 | |
| 3535124 | 6 PLUG AS (7/16-20-THD) | 1 | |
| 6V3250 | SEAL-O-RING | 1 | |
| 9S8004 | PLUG (9/16-18-THD) | 1 | |
| 3535125 | 7 PLUG AS (9/16-18-THD) | 1 | |
| 6V3251 | SEAL-O-RING | 1 | |
| 9S8006 | PLUG (7/8-14-THD) | 1 | |
| 2242675 | 8 SEAL | 1 | |
| 3048008 | 9 PLUG AS | 1 | |
| 6V9027 | SEAL-O-RING | 1 | |
| 9S8002 | PLUG (7/16-20-THD) | 1 | |
| 3359214 | 10 CLAMP-BAND | 2 | |
| 6V2317 | 11 BOLT (M8X1.25X30-MM) | 5 | |
| 6V5219 | 12 BOLT (M8X1.25X40-MM) | 5 | |
| 6V5221 | 13 BOLT (M8X1.25X80-MM) | 1 | |
| 8E9571 | 14 WASHER-HARD (8.8X16X7-MM THK) | 1 | |
| 9M1974 | 15 WASHER-HARD (8.8X16X2-MM THK) | 10 |
