System And Components
297-5511 COOLER GP-ENGINE OILS/N LGK1-UP
Group No: 297-5511
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1245043 | 1 COUPLING | 1 | |
| 1316645 | 2 HOSE | 1 | |
| 2242675 | 3 SEAL | 1 | |
| 3411429 | 4 SEAL | 2 | |
| 2304518 | 5 ELBOW | 1 | |
| 3493313 | 6 BONNET (OIL COOLER) | 1 | |
| 2368745 | 7 CORE AS-OIL COOLER (ENGINE) | 1 | |
| 3476922 | 8 BONNET-OIL COOLER (REAR) | 1 | |
| 2N5243 | 9 SEAL-O-RING | 2 | |
| 3359214 | 10 CLAMP-BAND | 2 | |
| 6V2317 | 11 BOLT (M8X1.25X30-MM) | 5 | |
| 3535125 | 12 PLUG AS | 1 | |
| 9S8006 | PLUG (7/8-14-THD) | 1 | |
| 6V3251 | 12A SEAL-O-RING | 1 | |
| 3535144 | 13 PLUG AS | 1 | |
| 9S9334 | PLUG (1-5/16-12-THD) | 1 | |
| 6V5064 | 13A SEAL-O-RING | 1 | |
| 6V5219 | 14 BOLT (M8X1.25X40-MM) | 5 | |
| 6V5221 | 15 BOLT (M8X1.25X80-MM) | 1 | |
| 3048008 | 16 PLUG AS | 1 | |
| 9S8002 | PLUG (7/16-20-THD) | 1 | |
| 6V9027 | 16A SEAL-O-RING | 1 | |
| 9M1974 | 17 WASHER-HARD (8.8X16X2-MM THK) | 16 | |
| 6V5218 | 18 BOLT (M8X1.25X35-MM) | 5 |
