244-8674 COOLER GP-TRANSMISSION OILS/N LGK1-UP

Group No: 244-8674

Part Number	Part Name	Qty
2S0795	1 GASKET	2
4W9822	2 CORE GP-OIL COOLER (TRANSMISSION OIL)(TRANSMISSION)	1
8E9571	3 WASHER-HARD (8.8X16X7-MM THK)	2
8M9307	4 PLUG (TRANSMISSION OIL COOLER)	1
8S4304	5 BONNET-XMSN OIL COOLER	1
1245043	6 COUPLING	1
1451750	7 BRACKET	1
5V6103	8 SPACER (14.27X22.23X70-MM THK)	2
3493309	9 ELBOW	1
2313178	10 BRACKET	1
0S1587	11 BOLT (1/2-13X1.75-IN)	4
0S1595	12 BOLT (1/2-13X1.25-IN)	4
9S9334	13 PLUG (1-5/16-12-THD)	1
9S8004	14 PLUG (9/16-18-THD)	1
2N5243	15 SEAL-O-RING	2
3E4353	16 WASHER-HARD (11X25X3-MM THK)	2
5P8245	17 WASHER-HARD (13.5X25.5X3-MM THK)	8
6F7062	18 WASHER (12.7X19.05X1.83-MM THK)	1
6V1820	19 BOLT (M10X1.5X30-MM)	2
6V3668	20 BOLT (M12X1.75X30-MM)	2
6V5219	21 BOLT (M8X1.25X40-MM)	5
6V5839	22 WASHER (11X21X2.5-MM THK)	2
2104460	23 BOLT (M10X1.5X130-MM)	2
9M1974	24 WASHER-HARD (8.8X16X2-MM THK)	3
9X8873	25 BOLT (1/2-13X2.25-IN)	2
7X0333	26 BOLT (1/2-13X4.75-IN)	2
6V3250	27 SEAL-O-RING	1
8T4223	28 WASHER-HARD (13.5X25.5X3-MM THK)	2
3411429	29 SEAL	1
6V5064	30 SEAL-O-RING	1
