System And Components
288-6340 RADIATOR GPS/N LGK1-UP
Group No: 288-6340
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8F8151 | 1 VALVE-SHUTOFF | 1 | |
| 2284305 | 2 CHANNEL AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 4 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 4 | |
| 2886343 | 3 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 11 | |
| 9X6269 | NUT-WELD (M16X2-THD) | 2 | |
| 2886345 | 4 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 10 | |
| 2886346 | 5 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 5 | |
| 2886347 | 6 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 10 | |
| 2886348 | 7 BAFFLE | 1 | |
| 3034384 | 8 CORE AS-RADIATOR | 1 | |
| 3076558 | 9 CORE AS-AFTERCOOLER | 1 | |
| 3048008 | 10 PLUG AS | 1 | |
| 9S8002 | PLUG (7/16-20-THD) | 1 | |
| 6V9027 | 10A SEAL-O-RING | 1 | |
| 5C9553 | 11 BOLT (M6X1X16-MM) | 2 | |
| 8T4121 | 12 WASHER-HARD (11X21X2.5-MM THK) | 39 | |
| 8T4133 | 13 NUT (M10X1.5-THD) | 4 | |
| 8T4136 | 14 BOLT (M10X1.5X25-MM) | 31 | |
| 8T4198 | 15 BOLT (M10X1.5X100-MM) | 4 | |
| 9X8256 | 16 WASHER (6.6X12X2-MM THK) | 2 |
