System And Components
288-6350 RADIATOR GPS/N LGK1-UP
Group No: 288-6350
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3603665 | 1 ELBOW AS | 1 | |
| 6V6609 | SEAL-O-RING | 1 | |
| 9X3966 | ELBOW | 1 | |
| 5P1259 | 2 HOSE | 1 | |
| 6L8617 | 3 CAP-PRESSURE (7-PSI)(RADIATOR) | 1 | |
| 8D3786 | 4 MOUNTING | 2 | |
| 8T1117 | 5 CLAMP-HOSE | 4 | |
| 8T4984 | 6 CLAMP-HOSE | 5 | |
| 1095351 | 7 HOSE-RADIATOR | 1 | |
| 2284310 | 8 BRACE | 2 | |
| 2886340 | 9 RADIATOR GP | 1 | |
| 2886341 | 10 SUPPORT AS | 1 | |
| 2886342 | 11 SUPPORT AS | 1 | |
| 2886351 | 12 GUARD AS-FAN | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 3 | |
| 2886352 | 13 BRACKET | 1 | |
| 2886353 | 14 HOSE | 1 | |
| 2886354 | 15 TUBE | 1 | |
| 2886355 | 16 TUBE | 1 | |
| 1184977 | 17 BOLT (M16X2X65-MM) | 2 | |
| 1877331 | 18 MOUNT-RUBBER | 4 | |
| 2L9653 | 19 CLIP | 1 | |
| 4S4455 | 20 CLIP | 1 | |
| 5P1076 | 21 WASHER-HARD (13.5X30X4-MM THK) | 2 | |
| 3603664 | 22 CONNECTOR AS | 1 | |
| 6V1722 | ADAPTER | 1 | |
| 6V5063 | SEAL-O-RING | 1 | |
| 7X0607 | 24 WASHER-HARD (20X55X8-MM THK) | 2 | |
| 7X0618 | 25 WASHER-HARD (13.5X40X5-MM THK) | 4 | |
| 7X0384 | 26 BOLT (7/8-9X3-IN) | 8 | |
| 7X7729 | 27 WASHER (11X25X3-MM THK) | 16 | |
| 1860712 | 29 PLATE | 4 | |
| 8T4121 | 30 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 8T4133 | 31 NUT (M10X1.5-THD) | 3 | |
| 8T4136 | 32 BOLT (M10X1.5X25-MM) | 17 | |
| 8T4137 | 33 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4139 | 34 BOLT (M12X1.75X30-MM) | 2 | |
| 8T4195 | 36 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4223 | 37 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4244 | 38 NUT (M12X1.75-THD) | 2 | |
| 8T4648 | 39 BOLT (M12X1.75X70-MM) | 2 | |
| 8T6765 | 40 PLUG-PIPE (1/4-18-THD) | 1 | |
| 9X8257 | 41 WASHER (17.5X30X3.5-MM THK) | 2 | |
| 3718094 | 42 HOSE (7.5-CM EACH) | ||
| 5P5991 | 43 HOSE (0.3-M) | ||
| 8C6913 | 44 WASHER-HARD (24X41.5X4-MM THK) | 8 | |
| 8T6703 | 45 CLAMP-HOSE | 1 |
