System And Components
288-6356 LINES GP-AIRS/N LGK1-UP
Group No: 288-6356
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7E8630 | 1 HOSE-AIR INLET | 3 | |
| 9X2201 | 2 CLAMP-HOSE | 12 | |
| 1260073 | 3 ELBOW | 1 | |
| 1270929 | 4 CLAMP-V BAND | 1 | |
| 2484840 | 5 CAP-PROTECTIVE | 1 | |
| 2484841 | 6 CLAMP-BAND | 1 | |
| 2762181 | 7 ELBOW-AIR INLET | 1 | |
| 2886357 | 8 TUBE | 1 | |
| 2886358 | 9 TUBE | 1 | |
| 2969821 | 10 BRACKET | 1 | |
| 3307226 | 11 ELBOW | 1 | |
| 3072671 | 12 PLUG AS | 1 | |
| 9S8002 | PLUG (7/16-20-THD) | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 6V6782 | 13 CLIP (SLOT) | 1 | |
| 6V6783 | 14 CLIP (TAB) | 1 | |
| 7X7729 | 15 WASHER (11X25X3-MM THK) | 2 | |
| 8C3089 | 16 SEAL-O-RING | 1 | |
| 8T4121 | 17 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4133 | 18 NUT (M10X1.5-THD) | 1 | |
| 8T4136 | 19 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4196 | 20 BOLT (M10X1.5X35-MM) | 1 | |
| 8T4986 | 21 CLAMP-HOSE | 4 | |
| 8T6757 | 22 PLUG-PIPE | 1 |
