System And Components
291-5529 COOLER GP-FUELS/N LGK1-UP
Group No: 291-5529
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1343196 | 1 WASHER (10.2X39.6X2.3-MM THK) | 6 | |
| 7W7536 | 2 HOSE AS | 1 | |
| 8X9882 | 4 PLATE | 1 | |
| 1295429 | 5 CORE AS-FUEL COOLER (RADIATOR) | 1 | |
| 1411060 | 6 MOUNT-ISOLATION | 8 | |
| 2601549 | 7 BRACKET AS | 1 | |
| 2776240 | 8 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 4 | |
| 3535134 | 9 ELBOW AS | 1 | |
| 1184728 | ELBOW | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 4L6454 | 10 BOLT (3/8-16X1-IN) | 4 | |
| 5P1075 | 11 WASHER-HARD (10.2X22.5X3-MM THK) | 6 | |
| 8T1889 | 12 CLIP (SLOT) | 1 | |
| 6V8801 | 13 NUT (3/8-16-THD) | 1 | |
| 8T1890 | 14 CLIP (TAB) | 1 | |
| 8M0547 | 15 ELBOW-FLARED (SWIVEL) | 1 | |
| 8T8915 | 16 BOLT (3/8-16X3.25-IN) | 4 | |
| 8T2502 | 17 BOLT (3/8-16X1.125-IN) | 1 | |
| 5P8939 | 18 GROMMET | 1 | |
| 6C3241 | 19 BOLT (1/2-13X1.5-IN) | 1 | |
| 8T4223 | 20 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 6V8188 | 21 NUT (1/2-13-THD) | 1 | |
| 9L8781 | 22 WASHER (0.406X1.5X0.188-IN THK) | 2 |
