System And Components
356-4878 COOLER GP-FUELS/N LGK1-UP
Group No: 356-4878
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6I7984 | 1 HOSE AS | 1 | |
| 1122565 | 2 ADAPTER | 1 | |
| 1208234 | 3 BRACE | 1 | |
| 1295429 | 4 CORE AS-FUEL COOLER | 1 | |
| 1411060 | 5 MOUNT-ISOLATION | 8 | |
| 2601549 | 6 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 4 | |
| 2776240 | 7 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 4 | |
| 2287090 | 8 SEAL-O-RING | 1 | |
| 8T4226 | 9 WASHER-PLATED (10.5X45X3-MM THK) | 8 | |
| 4L6454 | 10 BOLT (3/8-16X1-IN) | 5 | |
| 5P1075 | 11 WASHER-HARD (10.2X22.5X3-MM THK) | 8 | |
| 5P7462 | 12 CLIP (SLOT) | 2 | |
| 5P7463 | 13 CLIP (TAB) | 2 | |
| 6V0683 | 14 GROMMET | 2 | |
| 6V8801 | 15 NUT (3/8-16-THD) | 2 | |
| 9B7237 | 16 BOLT (3/8-16X1.25-IN) | 1 | |
| 8T8915 | 17 BOLT (3/8-16X3.25-IN) | 4 |
