System And Components
243-3026 FILTER GP-FUELS/N LGK1-UP
Group No: 243-3026
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P8939 | 1 GROMMET | 1 | |
| 6I4027 | 2 HOSE AS | 1 | |
| 8T1889 | 3 CLIP (SLOT) | 1 | |
| 2433027 | 4 BRACKET AS | 1 | |
| 2433028 | 5 BRACKET | 1 | |
| 2129431 | 6 FILTER GP-WATER SEP & FUEL | 1 | |
| 2Y5829 | 7 NUT (M10X1.5-THD) | 4 | |
| 3031506 | 8 ELBOW AS | 2 | |
| 4K6297 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1637451 | 9 BRACKET | 1 | |
| 5P8245 | 10 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 6V3822 | 11 BOLT (M10X1.5X35-MM) | 4 | |
| 6V4248 | 12 BOLT (M10X1.5X25-MM) | 1 | |
| 8T1890 | 13 CLIP (TAB) | 7 | |
| 6V5684 | 14 BOLT (M12X1.75X45-MM) | 1 | |
| 6V5839 | 15 WASHER (11X21X2.5-MM THK) | 9 | |
| 6V8149 | 16 NUT (M12X1.75-THD) | 2 | |
| 6V8197 | 17 BOLT (M12X1.75X40-MM) | 1 | |
| 8T4121 | 18 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 3079615 | 19 ADAPTER AS | 1 | |
| 8M0505 | ADAPTER | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 1833407 | 20 PLUG AS | 5 | |
| 9S8004 | PLUG (9/16-18-THD) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 8T4133 | 21 NUT (M10X1.5-THD) | 1 | |
| 8T4195 | 22 BOLT (M10X1.5X30-MM) | 1 |
