System And Components
419-8539 LINES GP-FUELS/N LGK1-UP
Group No: 419-8539
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 3 | |
| 1230783 | 2 VALVE GP-FLUID SAMPLING (FUEL) | 1 | |
| 2490164 | 3 HOSE AS | 1 | |
| 2746719 | 4 SENSOR GP-PRESSURE (FUEL) | 1 | |
| 2788844 | 5 PLUG AS-CONNECTOR | 1 | |
| 8T8737 | PLUG-SEAL | 2 | |
| 2304011 | PLUG AS-CONNECTOR (2-PIN) | 1 | |
| 4550704 | SEAL-CONNECTOR | 1 | |
| 3256995 | 6 CLIP (TAB) | 1 | |
| 3609145 | 7 HARNESS AS-SENSOR (FUEL) | 1 | |
| 3866196 | 8 ELBOW AS | 1 | |
| 0307943 | ELBOW | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3882619 | 9 BRACKET AS | 1 | |
| 3882621 | 10 HOSE & TUBE AS | 1 | |
| 3882622 | 11 HOSE & TUBE AS | 1 | |
| 1759079 | 12 ROD-LINK | 1 | |
| 3918662 | 13 PLUG AS | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 1236948 | PLUG | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 3985596 | 14 PLUG AS | 3 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3603680 | PLUG (3/4-16-THD) | 1 | |
| 4198569 | 15 HOSE AS | 2 | |
| 1325789 | 16 CLIP (LADDER) | 1 | |
| 1917805 | 17 ELBOW AS | 1 | |
| 0307947 | ADAPTER-ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2Y5829 | 18 NUT (M10X1.5-THD) | 1 | |
| 3031506 | 19 ELBOW AS | 1 | |
| 4K6297 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3139614 | 20 ADAPTER AS | 1 | |
| 2R6806 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3218654 | 21 ADAPTER AS | 1 | |
| 3P1932 | ADAPTER | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3218671 | 22 CONNECTOR AS | 1 | |
| 0308188 | CONNECTOR | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3256994 | 23 CLIP (SLOT) | 1 | |
| 3309732 | 24 ADAPTER AS | 1 | |
| 5P6944 | ADAPTER | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3535102 | 25 FITTING AS-ELBOW | 2 | |
| 0054362 | ELBOW | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3535111 | 26 ADAPTER AS | 2 | |
| 7D9984 | ELBOW | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3535112 | 27 ADAPTER AS | 1 | |
| 9X0262 | ADAPTER | 1 | |
| 2147566 | SEAL-O-RING | 2 | |
| 3E4353 | 28 WASHER-HARD (11X25X3-MM THK) | 2 | |
| 3K1787 | 29 GROMMET | 1 | |
| 5P8939 | 30 GROMMET | 1 | |
| 6V4248 | 31 BOLT (M10X1.5X25-MM) | 1 | |
| 6V5839 | 32 WASHER (11X21X2.5-MM THK) | 1 | |
| 6V6317 | 34 BOLT (M10X1.5X20-MM) | 1 | |
| 8T1889 | 35 CLIP (SLOT) | 1 | |
| 8T1890 | 36 CLIP (TAB) | 1 | |
| 8C5064 | 37 CONDUIT-FLEXIBLE (17.75-MM ID, SPLIT)(11-CM) | ||
| 2066876 | 38 CAP-TUBE | 1 | |
| 2345013 | 39 SENSOR GP-TEMPERATURE (FUEL) | 1 | |
| 3023908 | 40 SPACER (11X20X30-MM THK) | 1 |
