System And Components
286-5007 LINES GP-FUEL FILTERS/N LGK1-UP
Group No: 286-5007
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P0436 | 1 GASKET (FUEL PRIMING PUMP) | 1 | |
| 3S2093 | 2 STRAP-CABLE | 6 | |
| 6V0852 | 3 CAP-DUST | 1 | |
| 2175449 | 4 SPACER (11X20X30-MM THK) | 1 | |
| 7C8246 | 5 SPACER (10.5X20X24-MM THK) | 1 | |
| 9J6189 | 6 CLIP | 1 | |
| 9S1803 | 7 BOSS | 1 | |
| 3535112 | 8 ADAPTER AS | 1 | |
| 9X0262 | ADAPTER | 1 | |
| 2147566 | SEAL-O-RING | 2 | |
| 3918662 | 9 PLUG AS | 1 | |
| 1236948 | PLUG | 1 | |
| 7L9061 | SEAL-O-RING | 1 | |
| 1375541 | 10 PUMP GP-FUEL PRIMING (HAND) | 1 | |
| 3826044 | 11 VALVE GP-CHECK | 1 | |
| 1759079 | 12 ROD-LINK | 1 | |
| 1910483 | 13 HOSE AS | 2 | |
| 2336148 | 14 HOSE AS | 1 | |
| 2336742 | 15 VALVE GP-CHECK (FUEL) | 1 | |
| 2345013 | 16 SENSOR GP-TEMPERATURE (FUEL) | 1 | |
| 2379314 | 17 BASE AS | 1 | |
| 9S4167 | STUD-HOLLOW (1-14X1.47-IN) | 1 | |
| 1946725 | 18 SENSOR GP-PRESSURE (FUEL) | 1 | |
| 2726668 | 19 HOSE AS | 1 | |
| 2763104 | 20 HARNESS AS-ENGINE (FUEL FILTER) | 1 | |
| 2788844 | 21 PLUG AS-CONNECTOR | 1 | |
| 2304011 | PLUG AS-CONNECTOR (2-PIN) | 1 | |
| 8T8737 | PLUG-SEAL | 2 | |
| 3535102 | 23 FITTING AS-ELBOW | 2 | |
| 0054362 | ELBOW | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3535103 | 24 ADAPTER AS | 1 | |
| 0307942 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1917805 | 25 ELBOW AS | 3 | |
| 2147568 | SEAL-O-RING | 1 | |
| 0307947 | ADAPTER-ELBOW | 1 | |
| 3218671 | 26 CONNECTOR AS | 2 | |
| 0308188 | CONNECTOR | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3072673 | 27 PLUG AS | 1 | |
| 9S8005 | PLUG (3/4-16-THD) | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 1325789 | 28 CLIP (LADDER) | 2 | |
| 1697397 | 29 ADAPTER AS (STORAGE O-RING) | 1 | |
| 3P1932 | ADAPTER | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 2067337 | 30 TUBE AS | 1 | |
| 2Y5829 | 31 NUT (M10X1.5-THD) | 2 | |
| 9M1974 | 32 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 5P0537 | 33 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 3309732 | 34 ADAPTER AS | 1 | |
| 5P6944 | ADAPTER | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 8T0640 | 35 BOLT (M6X1X30-MM) | 1 | |
| 1645567 | 36 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 6V4249 | 37 BOLT (M10X1.5X50-MM) | 1 | |
| 7V6571 | 38 GROMMET | 1 | |
| 8T1889 | 39 CLIP (SLOT) | 1 | |
| 8T1890 | 40 CLIP (TAB) | 2 | |
| 6V5218 | 41 BOLT (M8X1.25X35-MM) | 1 | |
| 6V5839 | 42 WASHER (11X21X2.5-MM THK) | 8 | |
| 6V5842 | 43 BOLT (M10X1.5X40-MM) | 2 | |
| 6V5843 | 44 BOLT (M10X1.5X45-MM) | 1 | |
| 6V6317 | 45 BOLT (M10X1.5X20-MM) | 2 | |
| 7K4129 | 46 UNION-FLARED | 1 |
