System And Components
358-8540 LINES GP-FUEL FILTERS/N LGK1-UP
Group No: 358-8540
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P0436 | 1 GASKET (FUEL PRIMING PUMP) | 1 | |
| 3S2093 | 2 STRAP-CABLE | 5 | |
| 7C8246 | 3 SPACER (10.5X20X24-MM THK) | 2 | |
| 9J6189 | 4 CLIP | 1 | |
| 9S1803 | 5 BOSS | 1 | |
| 1236948 | 6 PLUG | 1 | |
| 1375541 | 7 PUMP GP-FUEL PRIMING | 1 | |
| 0617539 | SEAL-O-RING | 1 | |
| 2293218 | VALVE AS (FUEL PRIMING PUMP) | 2 | |
| 1396873 | 8 VALVE GP-FUEL BYPASS (FILTER) | 1 | |
| 1759079 | 9 ROD-LINK | 1 | |
| 1910483 | 10 HOSE AS | 2 | |
| 2336148 | 11 HOSE AS | 1 | |
| 2336742 | 12 VALVE GP-CHECK (FUEL)(FUEL INJECTOR BACK PRESSURE) | 1 | |
| 2345013 | 13 SENSOR GP-TEMPERATURE (FUEL) | 1 | |
| 2353596 | 14 ADAPTER AS | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 2353595 | ADAPTER | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 2379314 | 15 BASE AS | 1 | |
| 9S4167 | STUD-HOLLOW (1-14X1.47-IN) | 1 | |
| 2726668 | 16 HOSE AS | 1 | |
| 2746719 | 17 SENSOR GP-PRESSURE (FUEL) | 1 | |
| 2788844 | 18 PLUG AS-CONNECTOR | 1 | |
| 8T8737 | PLUG-SEAL | 2 | |
| 2304011 | PLUG AS-CONNECTOR (2-PIN) | 1 | |
| 2647029 | SEAL-CONNECTOR | 1 | |
| 3590965 | 20 HARNESS AS-ENGINE | 1 | |
| 1028806 | KIT-RECEPTACLE (8-PIN) | 1 | |
| 3E3389 | WEDGE-RECEPTACLE LOCK (8-PIN) | 1 | |
| 8T8737 | PLUG-SEAL | 1 | |
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 5 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 5 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 9 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 9 | |
| 2304011 | PLUG AS-CONNECTOR (2-PIN) | 1 | |
| 2647029 | SEAL-CONNECTOR | 1 | |
| 2304012 | RECEPTACLE AS-CONNECTOR (2-PIN) | 1 | |
| 2370227 | PLUG AS-CONNECTOR (3-PIN) | 1 | |
| 2647030 | SEAL-CONNECTOR | 1 | |
| 1325789 | 21 CLIP (LADDER) | 1 | |
| 1645567 | 22 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1917805 | 23 ELBOW AS | 3 | |
| 0307947 | ADAPTER-ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2067337 | 24 TUBE AS | 1 | |
| 2287091 | 25 SEAL-O-RING | 1 | |
| 2385081 | 26 SEAL-O-RING | 2 | |
| 2Y5829 | 27 NUT (M10X1.5-THD) | 2 | |
| 3072673 | 28 PLUG AS | 1 | |
| 9S8005 | PLUG (3/4-16-THD) | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3218671 | 29 CONNECTOR AS | 2 | |
| 0308188 | CONNECTOR | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3309732 | 30 ADAPTER AS | 1 | |
| 5P6944 | ADAPTER | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3535102 | 31 FITTING AS-ELBOW | 2 | |
| 0054362 | ELBOW | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3535103 | 32 ADAPTER AS | 1 | |
| 0307942 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 5P0537 | 33 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 6V0852 | 34 CAP-DUST | 1 | |
| 6V4249 | 35 BOLT (M10X1.5X50-MM) | 1 | |
| 6V5218 | 36 BOLT (M8X1.25X35-MM) | 1 | |
| 6V5839 | 37 WASHER (11X21X2.5-MM THK) | 8 | |
| 6V5842 | 38 BOLT (M10X1.5X40-MM) | 2 | |
| 6V5843 | 39 BOLT (M10X1.5X45-MM) | 1 | |
| 6V6317 | 40 BOLT (M10X1.5X20-MM) | 2 | |
| 7K4129 | 41 UNION-FLARED | 1 | |
| 7V6571 | 42 GROMMET | 1 | |
| 8T0640 | 43 BOLT (M6X1X30-MM) | 1 | |
| 8T1889 | 44 CLIP (SLOT) | 1 | |
| 8T1890 | 45 CLIP (TAB) | 1 | |
| 9M1974 | 46 WASHER-HARD (8.8X16X2-MM THK) | 1 |
