System And Components
360-1587 LINES GP-FUEL FILTERS/N LGK1-UP
Group No: 360-1587
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P0436 | 1 GASKET (FUEL PRIMING PUMP) | 1 | |
| 3S2093 | 2 STRAP-CABLE | 1 | |
| 7E2871 | 3 HOSE AS | 1 | |
| 1230783 | 4 VALVE GP-FLUID SAMPLING (FUEL)(FUEL) | 1 | |
| 1375541 | 6 PUMP GP-FUEL PRIMING | 1 | |
| 2293218 | VALVE AS (FUEL PRIMING PUMP) | 2 | |
| 2157350 | 8 BRACKET | 1 | |
| 2275722 | 9 TUBE AS | 1 | |
| 2336742 | 10 VALVE GP-CHECK (FUEL)(FUEL INJECTOR BACK PRESSURE) | 1 | |
| 2345013 | 11 SENSOR GP-TEMPERATURE (FUEL) | 1 | |
| 2353596 | 12 ADAPTER AS | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 2353595 | ADAPTER | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 2379314 | 13 BASE AS | 1 | |
| 9S4167 | STUD-HOLLOW (1-14X1.47-IN) | 1 | |
| 3882622 | 14 HOSE & TUBE AS | 1 | |
| 3882621 | 15 HOSE & TUBE AS | 1 | |
| 2746719 | 16 SENSOR GP-PRESSURE (FUEL) | 1 | |
| 2788844 | 17 PLUG AS-CONNECTOR | 1 | |
| 8T8737 | PLUG-SEAL | 2 | |
| 2304011 | PLUG AS-CONNECTOR (2-PIN) | 1 | |
| 2647029 | SEAL-CONNECTOR | 1 | |
| 3609145 | 18 HARNESS AS-SENSOR (FUEL FILTER) | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 9 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 9 | |
| 2304011 | PLUG AS-CONNECTOR (2-PIN) | 1 | |
| 2647029 | SEAL-CONNECTOR | 1 | |
| 2370227 | PLUG AS-CONNECTOR (3-PIN) | 1 | |
| 2647030 | SEAL-CONNECTOR | 1 | |
| 8T8737 | PLUG-SEAL | 1 | |
| 1028806 | KIT-RECEPTACLE (8-PIN) | 1 | |
| 2304012 | RECEPTACLE AS-CONNECTOR (2-PIN) | 1 | |
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 5 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 5 | |
| 1325789 | 19 CLIP (LADDER) | 1 | |
| 1759079 | 20 ROD-LINK | 1 | |
| 3031506 | 21 ELBOW AS | 1 | |
| 4K6297 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3918662 | 22 PLUG AS | 1 | |
| 7L9061 | SEAL-O-RING | 1 | |
| 1236948 | PLUG | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 3826044 | 23 VALVE GP-CHECK | 1 | |
| 3072673 | 24 PLUG AS | 1 | |
| 9S8005 | PLUG (3/4-16-THD) | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3139614 | 25 ADAPTER AS | 1 | |
| 2R6806 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3218671 | 26 CONNECTOR AS | 1 | |
| 0308188 | CONNECTOR | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3309732 | 27 ADAPTER AS | 1 | |
| 5P6944 | ADAPTER | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3535103 | 29 ADAPTER AS | 1 | |
| 0307942 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 5P0537 | 31 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 6V5218 | 34 BOLT (M8X1.25X35-MM) | 1 | |
| 6V5839 | 35 WASHER (11X21X2.5-MM THK) | 9 | |
| 6V5842 | 36 BOLT (M10X1.5X40-MM) | 3 | |
| 6V5843 | 37 BOLT (M10X1.5X45-MM) | 2 | |
| 6V6317 | 38 BOLT (M10X1.5X20-MM) | 3 | |
| 6Y1352 | 39 SPACER (10.5X20X27-MM THK) | 1 | |
| 7H7055 | 41 CLIP | 2 | |
| 7K4129 | 42 UNION-FLARED | 1 | |
| 8T0640 | 44 BOLT (M6X1X30-MM) | 1 | |
| 9M1974 | 45 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 2Y5829 | 46 NUT (M10X1.5-THD) | 1 | |
| 3K1787 | 47 GROMMET | 1 | |
| 5P8939 | 48 GROMMET | 1 | |
| 8T1889 | 49 CLIP (SLOT) | 1 | |
| 8T1890 | 50 CLIP (TAB) | 1 | |
| 3866196 | 51 ELBOW AS | 1 | |
| 0307943 | ELBOW | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3256994 | 52 CLIP (SLOT) | 1 | |
| 3256995 | 53 CLIP (TAB) | 1 | |
| 3882619 | 54 BRACKET AS | 1 |
